FSP Vita power supply unit 650 W 20+4 pin ATX ATX Black
(0 review)Add your review
€42,29

FSP Vita, 650 W, 200 - 240 V, 50/60 Hz, 4 A, Active, 100 W

Availability: In Stock
EAN:4711498480224Categories:PowerTags:

The Future is Now:ATX 3.1 ReadyFollowing the latest ATX 3.1 regulation, this series supports 200% power excursion and ensure peak performance with future hardware upgrades.+5V & 3.3V DC to DC Circuit DesignIncrease the efficiency and stabilize the output voltage to ensure system stability.Powerful Single +12V RailModern CPUs and graphics cards can draw significant amounts of power, especially during peak loads., a single +12V rail PSU offers a good balance of simplicity, power delivery capability, and stability.Premium, Black Flat CablesFeaturing improved black, flat cables that are soft and easy to bend, users can manage them more easily, saving time and creating more space for optimal cooling performance in your PC build.105˚C Japanese Bulk CapacitorThe bulk capacitor inside serves to support working under an extremely harsh environment, such as with high temperatures, peak voltage fluctuations. It stabilizes the performance for high reliability that your system can count on.Compact PSU size:140 x 150 x 86mm140mm in length which is relatively shorter than industry standard, it’s ideal for compact PC or space-constraint environment without compromising on performance.

Power
Total power650 W
AC input voltage200 - 240 V
AC input frequency50/60 Hz
Input current4 A
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)100 W
Combined power (+12V)650 W
Combined power (+5V)100 W
Combined power (-12V)3.6 W
Combined power (+5Vsb)15 W
Max output current (+3.3V)20 A
Max output current (+12V)54.17 A
Max output current (+5V)20 A
Max output current (-12V)0.3 A
Max output current (+5Vsb)3 A
Efficiency90 %
Power protection featuresOver current,Over power,Over voltage,Overheating,Short circuit,Under voltage
Ports & interfaces
Motherboard power connector20+4 pin ATX
Motherboard power cable length600 mm
Number of SATA power connectors8
SATA power cable length500 mm
Peripheral (Molex) power connectors (4-pin)4
PCI Express power connectors (6+2 pin)4
CPU power connector (4+4 pin)Y
CPU power cable length700 mm
Cabling typeNon-Modular
Performance
80 PLUS certification80 PLUS Bronze
PurposePC
Power supply unit (PSU) form factorATX
ATX version3.1
EPS version2.92
Bearing technologyHYB
Design
Product colourBlack
Cooling typeActive
Fan diameter120 mm
Number of fans1 fan(s)
Fan locationTop
Packaging content
Cables includedCPU,Peripheral (Molex),SATA
Weight & dimensions
Width150 mm
Depth140 mm
Height86 mm
