FSP Hydro Ti PRO 1000W power supply unit 20+4 pin ATX ATX Black
FSP Hydro Ti PRO 1000W, 1000 W, 100 - 240 V, 50/60 Hz, 13-6 A, 120 W, 1000 W
Availability: In Stock
New ATX PSU SpecificationsUpdated ATX 3.0 specifications for the next-generation hardware power demands and ensure users get the most stable and cost-optimized performance possible with the highest power efficiency.Ultra Power DensityCompared to general high-efficiency & high wattage PSU 170mm length, Hydro Ti PRO series delivers high power with shorter size of 150mm.80 Plus® Titanium CertificationHydro Ti PRO series is a power supply with 80 PLUS® Titanium provides over 94% efficiency at the load of 50 % and Cybenetics-certified for lower power consumption.Lambda A++ CertificationHydro Ti PRO ATX3.0(PCIe5.0) 1000W got Lambda A++ noise rating. By averaging the noise measurements that take from Cybenetics test results.Smarter, Quieter and Longer Lasting Eco Friendly FanUnder 50% loading, you will enjoy Zero RPM experience when eco semi-fanless fan control switch is on, , and get the benefit of long lifespan from a 135mm fluid dynamic bearing fan.Off-Wet, Off-Dust and Off-Stain CoatingCovered with exclusive conformal coating which guarantees to offer better and reliable performance in harsh environments and is tested to work in environments up to 95% relative humidity.LLC TopologyZero voltage switching of the main switches thereby dramatically lowering switching losses and boosting efficiency.450V, 105°C Japanese E-CapacitorsHydro Ti PRO series uses Japanese bulk capacitors to ensure a longer lifetime and protect your equipment from the infamous capacitor leakage problem.Unleash +12V Power OutputVGA card is a power-hungry component that needs most power. A single +12V rail design can deliver stable power and avoid any overloading conditions.Fully Modular Design Fully-modular design not just for easier installation, but also provides your system a neat and tidy look.Stylish & Changeable Side StickerIncludes unique side stickers for DIY enthusiasts and gamers.
| Power | |
|---|---|
| Total power | 1000 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 13-6 A |
| Combined power (+3.3V) | 120 W |
| Combined power (+12V) | 1000 W |
| Combined power (+5V) | 120 W |
| Combined power (-12V) | 18.6 W |
| Combined power (+5Vsb) | 18.6 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 83.33 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 94 % |
| Power protection features | Over current,Over power,Over voltage,Overheating,Short circuit |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 600 mm |
| Number of SATA power connectors | 12 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| PCI Express power connectors (6+2 pin) | 5 |
| PCI Express power connectors (12+4 pin) cable length | 700 mm |
| CPU power connector (4+4 pin) | Y |
| CPU power cable length | 700 mm |
| Cabling type | Fully-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Titanium |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.0 |
| EPS version | 2.92 |
| Noise level | 15 dB |
| Bearing technology | FDB |
| Design | |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 135 mm |
| Number of fans | 1 fan(s) |
| Fan location | Top |
| On/off switch | Y |
| Packaging content | |
| Cables included | CPU,PCIe,Peripheral (Molex),SATA |
| Weight & dimensions | |
| Width | 150 mm |
| Depth | 150 mm |
| Height | 86 mm |
