FSP Hydro Ti PRO 1000W power supply unit 20+4 pin ATX ATX Black
(0 review)Add your review
€185,39

FSP Hydro Ti PRO 1000W, 1000 W, 100 - 240 V, 50/60 Hz, 13-6 A, 120 W, 1000 W

Availability: In Stock
EAN:4713224527456Categories:PowerTags:

New ATX PSU SpecificationsUpdated ATX 3.0 specifications for the next-generation hardware power demands and ensure users get the most stable and cost-optimized performance possible with the highest power efficiency.Ultra Power DensityCompared to general high-efficiency & high wattage PSU 170mm length, Hydro Ti PRO series delivers high power with shorter size of 150mm.80 Plus® Titanium CertificationHydro Ti PRO series is a power supply with 80 PLUS® Titanium provides over 94% efficiency at the load of 50 % and Cybenetics-certified for lower power consumption.Lambda A++ CertificationHydro Ti PRO ATX3.0(PCIe5.0) 1000W got Lambda A++ noise rating. By averaging the noise measurements that take from Cybenetics test results.Smarter, Quieter and Longer Lasting Eco Friendly FanUnder 50% loading, you will enjoy Zero RPM experience when eco semi-fanless fan control switch is on, , and get the benefit of long lifespan from a 135mm fluid dynamic bearing fan.Off-Wet, Off-Dust and Off-Stain CoatingCovered with exclusive conformal coating which guarantees to offer better and reliable performance in harsh environments and is tested to work in environments up to 95% relative humidity.LLC TopologyZero voltage switching of the main switches thereby dramatically lowering switching losses and boosting efficiency.450V, 105°C Japanese E-CapacitorsHydro Ti PRO series uses Japanese bulk capacitors to ensure a longer lifetime and protect your equipment from the infamous capacitor leakage problem.Unleash +12V Power OutputVGA card is a power-hungry component that needs most power. A single +12V rail design can deliver stable power and avoid any overloading conditions.Fully Modular Design Fully-modular design not just for easier installation, but also provides your system a neat and tidy look.Stylish & Changeable Side StickerIncludes unique side stickers for DIY enthusiasts and gamers.

Power
Total power1000 W
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current13-6 A
Combined power (+3.3V)120 W
Combined power (+12V)1000 W
Combined power (+5V)120 W
Combined power (-12V)18.6 W
Combined power (+5Vsb)18.6 W
Max output current (+3.3V)20 A
Max output current (+12V)83.33 A
Max output current (+5V)20 A
Max output current (-12V)0.3 A
Max output current (+5Vsb)3 A
Efficiency94 %
Power protection featuresOver current,Over power,Over voltage,Overheating,Short circuit
Ports & interfaces
Motherboard power connector20+4 pin ATX
Motherboard power cable length600 mm
Number of SATA power connectors12
Peripheral (Molex) power connectors (4-pin)4
PCI Express power connectors (6+2 pin)5
PCI Express power connectors (12+4 pin) cable length700 mm
CPU power connector (4+4 pin)Y
CPU power cable length700 mm
Cabling typeFully-Modular
Performance
80 PLUS certification80 PLUS Titanium
PurposePC
Power supply unit (PSU) form factorATX
ATX version3.0
EPS version2.92
Noise level15 dB
Bearing technologyFDB
Design
Product colourBlack
Cooling typeActive
Fan diameter135 mm
Number of fans1 fan(s)
Fan locationTop
On/off switchY
Packaging content
Cables includedCPU,PCIe,Peripheral (Molex),SATA
Weight & dimensions
Width150 mm
Depth150 mm
Height86 mm
