Chieftec Value APB-600B8 power supply unit 600 W 20+4 pin ATX ATX Steel
€34,34
Chieftec Value APB-600B8, 600 W, 200 - 240 V, 600 W, 47 - 63 Hz, 4.5 A, 120 W
Availability: In Stock
The new VALUE SERIES offers both quality and 80 PLUS 230V EU efficiency at a highly competitive pricing. Equipped with a vast amount of required connectors, long native cables and a silent running fan with installed thermal board, the PSU runs quietly on full load and provides REAL POWER, thereby providing all security features. Certified by CE, CB, EAC, TÜV and amongst many others, it’s the VALUE choice!
| Power | |
|---|---|
| Total power | 600 W |
| Peak power | 600 W |
| AC input voltage | 200 - 240 V |
| AC input frequency | 47 - 63 Hz |
| Maximum input current (@220V) | 4.5 A |
| Combined power (+3.3V) | 120 W |
| Combined power (+12V) | 552 W |
| Combined power (+5V) | 120 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V1) | 46 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 550 mm |
| Number of SATA power connectors | 4 |
| SATA power cable length | 150,500 mm |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Peripheral (Molex) power cable length | 150,500 mm |
| EPS power connector (8-pin) | N |
| EPS power connector (4+4 pin) | Y |
| PCI Express power connectors (6+2 pin) | 2 |
| Floppy disk drive connector | Y |
| Floppy disk drive cable length | 150 mm |
| Cabling type | Non-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 2.3 |
| Design | |
| Product colour | Steel |
| Cooling type | Active |
| Fan diameter | 120 mm |
| Number of fans | 1 fan(s) |
| Fan location | Top |
| On/off switch | Y |
| Certificates | |
| Compliance certificates | CE,RoHS |
| Weight & dimensions | |
| Width | 150 mm |
| Depth | 140 mm |
| Height | 87 mm |
| Weight | 1420 g |
| Packaging data | |
| Package weight | 1560 g |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
