Chieftec CSN-550C power supply unit 550 W 20+4 pin ATX PS/2 Black
€69,54
Chieftec CSN-550C, 550 W, 100 - 240 V, 47 - 63 Hz, 6 A, Active, 90 W
Availability: In Stock
| Power | |
|---|---|
| Total power | 550 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 47 - 63 Hz |
| Input current | 6 A |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 90 W |
| Combined power (+5V) | 90 W |
| Max output current (+3.3V) | 18 A |
| Max output current (+12V1) | 45.8 A |
| Max output current (+5V) | 15 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 90 % |
| Power protection features | Over current,Over voltage,Overheating,Overload,Short circuit,Under voltage |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 4 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| PCI Express power connectors (6+2 pin) | 2 |
| CPU power connector (4+4 pin) | Y |
| ATX power connector (20+4 pin) | Y |
| Floppy drive power connector | 1 |
| Cabling type | Fully-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| Power supply unit (PSU) form factor | PS/2 |
| ATX version | 2.3 |
| Design | |
| Product colour | Black |
| Fan diameter | 80 mm |
| Number of fans | 1 fan(s) |
| Weight & dimensions | |
| Width | 125 mm |
| Depth | 100 mm |
| Height | 64 mm |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
