ASUS ROG STRIX B850-F GAMING WIFI AMD B850 Socket AM5 ATX
(0 review)Add your review
€258,32

ASUS ROG STRIX B850-F GAMING WIFI, AMD, Socket AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Socket AM5, DDR5-SDRAM, 192 GB

Availability:: Arriving soon
EAN:4711387771013Categories:Hardware Components

The ROG Strix B850-F Gaming WiFi is built to dominate with AMD Ryzen™ 9000 Series Desktop Processors. Its advanced power design and AI solutions ensure peak performance. In addition, the total support of 19 USB ports including USB 20Gbps, as well as WIFI 7 and 2.5Gbps ethernet, provides cutting-edge connectivity. This motherboard delivers the power and speed essential for elite gaming and the demands of advanced AI PC applications.ASUS AI INTELLIGENCEASUS AI ADVISORUsing AI technology to understand natural-language questions or scenario descriptions, ASUS AI Advisor allows users to explore the functionality and advanced features of ASUS motherboards in a simple and straightforward way.*Availability of ASUS AI Advisor may vary by region.**AI Advisor functions may vary by platform.AI NETWORKING IIAI Networking II combines intelligent technologies to continuously optimize network performance, provide trustworthy and seamless connectivity, and unleash the full speed of WiFi 7*.*Features may vary by model.OVERCLOCKINGPBO ENHANCEMENTAMD Precision Boost Overdrive (PBO) pushes the CPU current and voltage budget to opportunistically increase performance. By aggressively tuning the PBO parameters, AMD's algorithm can leverage the motherboard's robust power solution to ramp up performance even higher.MEMORYDDR5 DOMINATIONThe Strix B850-F is primed and ready for enthusiast-grade kits courtesy of vast AMD Extended Profiles for Overclocking (EXPO) support.AEMPASUS Enhanced Memory Profile (AEMP) is an exclusive firmware feature for PMIC-restricted memory modules.ROG STRIX ULTIMATE POWER DESIGN16(80A)+2(80A)+2(80A) Power StagesPLAY IN STYLEUNDENIABLY ROG STRIXThe ROG Strix B850-F is sleek and understated, empowering you to seamlessly combine it with a wide range of system components. Its deep black PCB and matching metallic heatsinks create a dark and intense look, while a touch of RGB lighting on the I/O shroud lets you either stay under the radar or make a bold statement.OUTSHINE THE COMPETITIONROG Strix motherboards feature ASUS Aura technology, enabling full lighting control and a variety of presets for both onboard RGB LEDs and third-party accessories. Effects can be easily synced across compatible ROG graphics cards, monitors, keyboards, and mice to give your setup a unified look.BUILD FOR THE MOST ADVANCED PC FOR GAMING AND CREATINGWhen only the fastest will do, a Strix B850 motherboard delivers. With USB 20Gbps onboard along with robust overclocking¹ capabilities, featuring faster dual-channel DDR5 memory support, AMD EXPO™ technology and PCIe® 5.0 support for both graphics and NVMe, you can play the most demanding games and deliver your biggest projects with the revolutionary performance of an AMD 800-series motherboard and AMD Ryzen™ 9000, 8000, and 7000 Series processors.Dare to Be GreenWe at the Republic of Gamers are on a mission to create a sustainable future where all gamers can flourish on the planet we call home.Every step counts, and as part of ROG’s commitment to creating a more sustainable future, ROG has begun to utilize post-consumer recycled (PCR) plastic and paper materials certified by the Forest Stewardship Council (FSC™) in the packaging of motherboard.

Processor
Processor manufacturerAMD
Processor socketSocket AM5
Compatible processor seriesAMD Ryzen 7000 Series,AMD Ryzen 8000 Series,AMD Ryzen 9000 Series
Supported processor socketsSocket AM5
Memory
Supported memory typesDDR5-SDRAM
Number of memory slots4
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilityECC & non-ECC
Supported memory clock speed (max)8000
Maximum internal memory192
Unbuffered memoryY
Storage controllers
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2,SATA III
Number of HDDs supported2
Number of storage drives supported6
RAID supportY
RAID levels0,1,5,10
Graphics
Parallel processing technology supportNot supported
On-board graphics cardN
Maximum resolution7680 x 4320
Internal I/O
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
USB 3.2 Gen 2 (3.1 Gen 2) connectors1
Number of SATA III connectors2
Front panel audio connectorY
Front panel connectorY
ATX Power connector (24-pin)Y
CPU fan connectorY
Number of CPU fan connectors2
Number of chassis fan connectors4
EPS power connector (8-pin)Y
Number of EPS power connectors (8-pin)2
Thunderbolt headers1
Number of water pump connectors1
Number of temperature sensor headers1
RGB LED pin headerY
Number of RGB LED pin headers3
Rear panel I/O ports
USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
USB 3.2 Gen 2x2 Type-C ports quantity1
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
HDMI version2.1
DisplayPorts quantity1
DisplayPort version1.4
Headphone outputs1
Line-inY
S/PDIF out portY
Digital audio optical out1
WiFi-AP antenna jack2
Network
Ethernet LANY
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiY
Top Wi-Fi standardWi-Fi 7 (802.11be)
Wi-Fi standardsWi-Fi 7 (802.11be)
BluetoothY
Bluetooth version5.4
Features
Motherboard chipsetAMD B850
Audio chipRealtek ALC4080
Audio output channels7.1
Product colourBlack
Component forPC
Motherboard form factorATX
Motherboard chipset familyAMD
Power source typeATX
Windows operating systems supportedWindows 11
Expansion slots
PCI Express x16 (Gen 4.x) slots1
PCI Express x16 (Gen 5.x) slots1
Number of M.2 (M) slots4
1st M.2 largest key size2280
1st M.2 highest PCI Express generation5.0
2nd M.2 largest key size22110
2nd M.2 highest PCI Express generation5.0
3rd M.2 largest key size2280
3rd M.2 highest PCI Express generation4.0
4th M.2 largest key size2280
4th M.2 highest PCI Express generation4.0
BIOS
BIOS typeUEFI AMI
BIOS memory size256
Clear CMOS buttonY
Packaging data
Package width353
Package depth273
Package height68
Package weight2060
Weight & dimensions
Width305
Depth244
Packaging content
Cables includedSATA
Antenna includedY
Other features
Weight1630
Quick installation guideY
