FSP Champ Tower 3K uninterruptible power supply (UPS) Double-conversion (Online) 3 kVA 2700 W
€391,89
FSP Champ Tower 3K, Double-conversion (Online), 3 kVA, 2700 W, Pure sine, 120 V, 300 V
Availability: In Stock
FSP Champ is the high density version of double-conversion online UPS with a output power factor 0.9. It’s designed in small cabinet with microprocessor controller.Champ also have USB and RS-232 communication ports as standard, with a built-in intelligent slot for additional adapters, protocol converters and relate contact cards.
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 3 |
| Output power | 2700 |
| Waveform | Pure sine |
| Input operation voltage (min) | 120 |
| Input operation voltage (max) | 300 |
| Input frequency | 40 - 70 |
| Output operation voltage (min) | 200 |
| Output operation voltage (max) | 240 |
| Output frequency | 47/63 |
| Output voltage regulation | 1 |
| Response time | 0 |
| Power factor | 0.99 |
| Crest factor | 3:1 |
| Noise level | 50 |
| Audible alarm(s) | Y |
| Audible alarm modes | Alarm when on battery,Fault,Low battery alarm,Overload alarm |
| Ports & interfaces | |
| AC outlet types | Type F |
| Number of output IEC jumpers | 4 |
| USB port | Y |
| USB 2.0 ports quantity | 1 |
| USB port type | USB Type-B |
| Serial interface | Y |
| Serial interface type | RS-232 |
| RS-232 ports | 1 |
| Battery | |
| Battery capacity | 9 |
| Battery voltage | 12 |
| Number of battery cells | 6 |
| Typical backup time at full load | 3.5 |
| Typical backup time at half load | 9.8 |
| Design | |
| Form factor | Rackmount/Tower |
| Product colour | Black |
| Control type | Buttons |
| Display type | LCD |
| LED indicators | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Operating relative humidity (H-H) | 20 - 90 |
| Packaging content | |
| Batteries included | Y |
| Cables included | Input power cable,USB cable |
| Manual | Y |
| Weight & dimensions | |
| Width | 190 |
| Depth | 421 |
| Height | 318 |
| Weight | 27600 |
