iiyama TE6515A-B1AG Signage Display Interactive flat panel 163.8 cm (64.5") Wi-Fi 550 cd/m² 4K Ultra HD Black Touchscreen Built-in processor Android
iiyama TE6515A-B1AG, Interactive flat panel, 163.8 cm (64.5"), 3840 x 2160 pixels, Wi-Fi
Availability:: Arriving soon
Elegance and functionality come together in the ProLite TE6515A-B1AG. This 65” 4K UHD panel not only delivers precision and performance, but also brings a premium look to modern classrooms and collaborative business environments. With its button-free front panel (only a discreet power button), integrated pen holders, and a stylish fabric-covered bottom bezel that subtly houses high-quality front-facing speakers, the TE6515A elevates the visual experience of any room. It’s more than a tool—it’s part of your space. Coupled with DeepContrast-IR+ technology and Palm Rejection, it offers fluid and natural writing on the Optical Bonding LCD, eliminating parallax for an intuitive feel. Powered by iiWare 21E with Android 14 (EDLA Certified), the display integrates effortlessly into Google environments. Features like WiFi6, Bluetooth 5.0 and PIR motion sensor add a layer of connectivity, energy efficiency, and access control. With iiControl (DMS), iiShare and integrated EShare app (wireless screen sharing), the TE6515A promotes seamless teamwork—whether you're presenting, teaching, or brainstorming. The TE6515A-B1AG isn’t just an interactive display—it’s a centerpiece for connection, creativity, and collaboration, all wrapped in a refined, modern design.
| Display | |
|---|---|
| Panel type | IPS |
| Display diagonal | 64.5 |
| Display resolution | 3840 x 2160 |
| Display brightness | 550 |
| HD type | 4K Ultra HD |
| Touchscreen | Y |
| Touchscreen technology | Infrared |
| Number of simultaneous touchpoints | 40 |
| Multi-touch | Y |
| Number of simultaneous touchpoints (Android) | 32 |
| Native aspect ratio | 16:9 |
| Response time | 8 |
| Contrast ratio (typical) | 1200:1 |
| Viewing angle, horizontal | 178 |
| Viewing angle, vertical | 178 |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.372 x 0.372 |
| Active display area (W x H) | 1428.5 x 803.5 |
| Display diagonal (metric) | 163.9 |
| Native refresh rate | 60 |
| Surface hardness | 7H |
| Glass thickness | 3.2 |
| Ports & interfaces | |
| HDMI ports quantity | 3 |
| HDMI version | 2.0 |
| HDMI input ports quantity | 1 |
| HDMI output ports quantity | 1 |
| DVI port | N |
| DisplayPorts quantity | 1 |
| DisplayPorts in | 1 |
| DisplayPort version | 1.2 |
| USB port | Y |
| USB ports quantity | 4 |
| USB connector type | USB Type-A,USB Type-C |
| USB Power Delivery (USB PD) | Y |
| USB Power Delivery up to | 100 |
| USB Type-C DisplayPort Alternate Mode | Y |
| Ethernet LAN (RJ-45) ports | 2 |
| RS-232C | Y |
| Card reader integrated | Y |
| Compatible memory cards | MicroSD (TransFlash) |
| OPS module slot | Y |
| Audio Return Channel (ARC) | Y |
| Audio | |
| Built-in speaker(s) | Y |
| Number of built-in speakers | 2 |
| RMS rated power | 60 |
| Design | |
| Product design | Interactive flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal |
| Product colour | Black |
| Screen shape | Flat screen |
| VESA mounting | Y |
| Panel mounting interface | 600 x 400 |
| Bezel colour | Black |
| Anti-glare screen | Y |
| Performance | |
| Purpose | Universal |
| Picture-in-Picture | Y |
| On Screen Display (OSD) | Y |
| Number of OSD languages | 14 |
| On Screen Display (OSD) languages | Multi |
| HDCP | Y |
| HDCP version | 2.2 |
| Mean time between failures (MTBF) | 50000 |
| Power | |
| Power consumption (typical) | 195 |
| Power consumption (standby) | 0.4 |
| Power consumption (off) | 0.3 |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 195 |
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| Energy efficiency scale | A to G |
| Computer system | |
| Built-in processor | Y |
| Processor manufacturer | ARM |
| Processor architecture | ARM Cortex-A53+Cortex-A72 |
| Processor cores | 7 |
| Internal memory | 16 |
| On-board graphics card model | ARM Mali-G52 |
| Internal storage capacity | 128 |
| Operating system installed | Android |
| Operating system version | 14 |
| Weight & dimensions | |
| Display width | 1489.1 |
| Display depth | 87.1 |
| Display height | 911.8 |
| Display weight | 43500 |
| Packaging data | |
| Package width | 1640 |
| Package depth | 1640 |
| Package height | 1010 |
| Package weight | 47400 |
| Packaging content | |
| Remote control included | Y |
| Batteries included | Y |
| Stylus pen | Y |
| Cables included | AC,HDMI,USB |
| Mounting kit | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Operating relative humidity (H-H) | -20 - 60 |
| Certificates | |
| Certification | CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, EPEAT, REACH (RoHS), EPEAT |
| Sensors | |
| Ambient light sensor | Y |
| Motion sensor | Y |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 1000 |
| Wi-Fi | Y |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Technical details | |
| OPS slot | 1 |
| Other features | |
| Quick start guide | Y |
| Audio input | Mini jack |
| Audio output | Mini jack |
| Bluetooth | Y |
| Bluetooth version | 5.0 |
| Power supply type | Internal |
