Sharp MultiSync P656 Kiosk design 163.8 cm (64.5") LCD 700 cd/m² 4K Ultra HD Black Built-in processor
Sharp MultiSync P656, Kiosk design, 163.8 cm (64.5"), LCD, 3840 x 2160 pixels
Availability:: Arriving soon
Precision performance for critical applicationsWhen reliability, security, and exceptional visual performance are mandatory, the Sharp MultiSync® P6 Series delivers with precision and resilience. Engineered for mission-critical applications and high-end signage, the P6 Series combines robust durability with advanced visual technologies to meet the most demanding commercial needs. With 700 cd/m² brightness, a high-haze panel, and SpectraViewTM Engine, it delivers outstanding image clarity and colour accuracy even in challenging lighting conditions. Despite its slim profile, the P6 Series is endorsed for use in heavy traffic spaces with a durable all-metal chassis that complies to the strictest fire safety standards.Building on NEC’s trusted heritage, the next generation Sharp P6 Series is designed for longevity and integration flexibility. Its modular architecture supports custom computing options by Intel® SDM or Raspberry Pi, and flexible connectivity including AVoverIP for versatile deployments. Native video daisy chaining via HDMI and DisplayPort enables content to be easily cloned or expanded across multiple displays. Compatibility with leading platforms such as Crestron, Cisco Webex, and Q-Sys enhances its future-proof appeal, while 802.1x LAN support safeguards robust security against cyber threats. Purpose-designed for control rooms, passenger information, and prestige retail or corporate signage, the P6 Series delivers uncompromising performance, day after day.
| Display | |
|---|---|
| Panel type | IPS |
| LED backlight | Y |
| LED backlighting type | Direct-LED |
| Display diagonal | 64.5 |
| Display technology | LCD |
| Display resolution | 3840 x 2160 |
| Display brightness | 700 |
| HD type | 4K Ultra HD |
| Native aspect ratio | 16:9 |
| Response time | 8 |
| Contrast ratio (typical) | 8000:1 |
| Viewing angle, horizontal | 178 |
| Viewing angle, vertical | 178 |
| Display number of colours | 1.073 billion colours |
| Pixel pitch | 0.375 x 0.375 |
| Display diagonal (metric) | 163.9 |
| Horizontal scan range | 15 - 135 |
| Vertical scan range | 23 - 76 |
| Native refresh rate | 60 |
| Ports & interfaces | |
| HDMI ports quantity | 3 |
| HDMI input ports quantity | 2 |
| DVI port | N |
| DisplayPorts quantity | 2 |
| DisplayPorts in | 1 |
| DisplayPorts out | 1 |
| USB port | Y |
| USB connector type | USB Type-A,USB Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Y |
| USB Power Delivery up to | 65 |
| USB Type-C DisplayPort Alternate Mode | Y |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 interface | Y |
| Audio | |
| Built-in speaker(s) | Y |
| Design | |
| Product design | Kiosk design |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| VESA mounting | Y |
| Panel mounting interface | 300 x 300 |
| Bezel width (bottom) | 13.9 |
| Bezel width (side) | 11 |
| Bezel width (top) | 11 |
| Performance | |
| Purpose | Retail |
| HDCP | Y |
| Web browser | Y |
| Power | |
| Power consumption (typical) | 160 |
| Power consumption (standby) | 0.5 |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | G |
| Energy consumption (SDR) per 1000 hours | 139 |
| Energy consumption (HDR) per 1000 hours | 137 |
| AC input voltage | 100 - 240 |
| AC input frequency | 50 - 60 |
| Energy efficiency scale | A to G |
| Computer system | |
| Computer system | Y |
| Built-in processor | Y |
| Processor manufacturer | Intel |
| Weight & dimensions | |
| Display width | 1454.5 |
| Display depth | 59.5 |
| Display height | 832.4 |
| Display weight | 17300 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Operating relative humidity (H-H) | 20 - 80 |
| Storage temperature (T-T) | -20 - 60 |
| Storage relative humidity (H-H) | 10 - 80 |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 100 |
| Wi-Fi | N |
| Technical details | |
| Sustainability certificates | ENERGY STAR |
| Safety warning | CE; EMC Class B; Energy Star 8; FCC Class B; REACH; RoHS; UKCA; UL/C-UL or CSA |
