Shuttle Nano PC NC4010BAV2, Intel Celeron 7305, 8GB DDR4, 128GB M.2, 1x HDMI, 1x DP, 7x USB, 1x LAN, incl. VESA and stand
Shuttle Nano PC NC4010BAV2, Intel Celeron 7305, 8GB DDR4, 128GB M.2, 1x HDMI, 1x DP, 7x USB, 1x LAN, incl. VESA and stand, Intel® Celeron®, 7305, 8 GB, 128 GB, Windows 11 Pro, 64-bit
Availability:: Arriving soon
MANY PORTS AND HIGH PERFORMANCE IN NANO-FORMATNC4010BA is a fully configured PC system in Nano-size with Windows 11 Pro operating system. It comes a with powerful and efficient 12th generation Intel ULV processor. Despite the small size with only 850 ml volume, it offers enormous connection variety and expansion options. Thus, up to three UHD displays (4K/60Hz) and up to seven USB 3.2 devices can be connected. This PC is ideal for Digital Signage, POS, control, office or even multimedia
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Celeron |
| Processor model | 7305 |
| Processor cores | 5 |
| Processor threads | 5 |
| Performance cores | 1 |
| Efficient cores | 4 |
| Processor cache | 8 |
| Processor cache type | Smart Cache |
| Number of processors installed | 1 |
| Processor base power | 15 |
| Maximum turbo power | 55 |
| Memory | |
| Internal memory | 8 |
| Maximum internal memory | 64 |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 2x SO-DIMM |
| Memory clock speed | 3200 |
| Non-ECC | Y |
| Storage | |
| Total storage capacity | 128 |
| Storage media | SSD |
| Optical drive type | N |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 128 |
| Number of SSDs installed | 1 |
| SSD capacity | 128 |
| SSD interface | PCI Express |
| NVMe | Y |
| SSD form factor | M.2 |
| Graphics | |
| Discrete graphics card | N |
| On-board graphics card | Y |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel UHD Graphics |
| On-board graphics card model | Intel UHD Graphics |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 10,100,1000 |
| LAN controller | Intel I219 |
| Wi-Fi | Y |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6 AX200 |
| Antenna type | 2x2 |
| Bluetooth | Y |
| Bluetooth version | 5.2 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0b |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4a |
| Ethernet LAN (RJ-45) ports | 1 |
| Microphone in | Y |
| Headphone outputs | 1 |
| DC-in jack | Y |
| Design | |
| Chassis type | Mini PC |
| Volume | 0.847 |
| Placement supported | Horizontal/Vertical |
| VESA mounting | Y |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Housing material | Plastic |
| Performance | |
| Market positioning | Business |
| Motherboard chipset | Intel SoC |
| BIOS type | UEFI AMI |
| Trusted Platform Module (TPM) | Y |
| Product type | Mini PC (<= 3L) |
| Software | |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 11 Pro |
| Drivers included | Y |
| Power | |
| Power supply | 65 |
| Power supply input voltage | 100 - 240 |
| Power supply input frequency | 50 - 60 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Operating relative humidity (H-H) | 10 - 90 |
| Certificates | |
| Compliance certificates | BSMI,CE,Federal Communications Commission (FCC),RoHS,UKCA,cTUVus |
| Sustainability | |
| Sustainability compliance | Y |
| Sustainability certificates | ENERGY STAR,ErP |
| Weight & dimensions | |
| Width | 42 |
| Depth | 142 |
| Height | 142 |
| Weight | 400 |
| Package weight | 1200 |
| Packaging content | |
| Cables included | AC |
| Power cable length | 1.7 |
| VESA mount included | Y |
| Screws included | Y |
| Logistics data | |
| Harmonized System (HS) code | 84714900 |
| Display | |
| Display included | N |
