Shuttle All-In-One Barebone P55U, 15.6" Multi-Touch-Screen, Celeron 7305, Wifi, IP54, fanless, 24/7 permanent operation
Shuttle All-In-One Barebone P55U, 15.6" Multi-Touch-Screen, Celeron 7305, Wifi, IP54, fanless, 24/7 permanent operation, All-in-One, All-in-One PC barebone, Intel SoC, LGA 1700, DDR5-SDRAM, PCI Express
Availability:: Arriving soon
The Shuttle XPC all-in-one PC series P55U comes with a capacitive 15.6" multi-touchscreen in Full-HD resolution and is powered by a Gen12/13 Intel ULV processor. The modern processor architecture has a very positive effect on power consumption and computing performance. The existing WLAN function can optionally be supplemented with a 4G/5G function with up to 4 antennas. Thanks to its passive heatpipe cooling, the system is virtually noiseless, maintenance-free and approved for 24/7 nonstop operation. Particularly suitable for vertical applications is the arrangement of connectors at the bottom and the IP54 compliant front panel which is dust-protected and protected from splashing of water.
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Celeron |
| Processor model | 7305 |
| Processor cores | 5 |
| Processor threads | 5 |
| Performance cores | 1 |
| Efficient cores | 4 |
| Built-in processor | Y |
| Processor cache | 8 |
| Memory | |
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 |
| Supported memory clock speeds | 4800 |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Memory voltage | 1.1 |
| ECC | N |
| Non-ECC | Y |
| Storage | |
| Supported storage drive types | SSD |
| Storage drive sizes supported | M.2 |
| SSD form factor | M.2 |
| Storage drive interface | PCI Express |
| NVMe | Y |
| Graphics | |
| On-board graphics card | Y |
| Graphics card family | Intel |
| On-board graphics card model | Intel UHD Graphics |
| Number of displays supported | 3 |
| Display | |
| Display diagonal | 15.6 |
| Display resolution | 1920 x 1080 |
| Touchscreen | Y |
| HD type | Full HD |
| Aspect ratio | 16:9 |
| Display brightness | 250 |
| Panel type | IPS |
| Audio | |
| Built-in speaker(s) | Y |
| Number of speakers | 2 |
| RMS rated power | 2 |
| Network | |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
| WLAN controller model | Realtek RTL8821CE |
| Ethernet LAN | Y |
| Wi-Fi | Y |
| LAN controller | Intel I219V |
| Bluetooth | Y |
| Bluetooth version | 4.2 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0b |
| VGA (D-Sub) ports quantity | 1 |
| Microphone in | Y |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| COM ports quantity | 2 |
| DC-in jack | Y |
| Expansion slots | |
| Number of M.2 (M) slots | 2 |
| Design | |
| Chassis type | All-in-one |
| Product colour | Black |
| Cooling type | Passive |
| LED indicators | Power,SSD |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| VESA mounting | Y |
| Panel mounting interface | 100 x 100 |
| Product type | All-in-One PC barebone |
| Performance | |
| Motherboard chipset | Intel SoC |
| Processor socket | LGA 1700 |
| Number of processors supported | 1 |
| BIOS type | AMI EEPROM |
| Built-in camera | Y |
| Trusted Platform Module (TPM) | Y |
| Trusted Platform Module (TPM) version | 2.0 |
| Audio chip | Realtek ALC888S |
| Technical details | |
| Compliance certificates | BSMI,CB,CE,Federal Communications Commission (FCC),RCM,RoHS,UKCA,VCCI,cTUVus |
| Logistics data | |
| Harmonized System (HS) code | 84714100 |
| Software | |
| Windows operating systems supported | Windows 10 x64,Windows 11 x64 |
| Linux operating systems supported | Y |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Power | |
| Power supply type | External AC adapter |
| Power supply | 90 |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| AC adapter output voltage | 19 |
| AC adapter output current | 4.74 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Operating relative humidity (H-H) | 10 - 90 |
| Weight & dimensions | |
| Width | 393.6 |
| Depth | 39.8 |
| Height | 272.5 |
| Weight | 3250 |
| Package weight | 4500 |
| Packaging content | |
| Power cord included | Y |
| AC adapter included | Y |
| Quick start guide | Y |
| Drivers included | Y |
