iiyama LH5075UHS-B2AG Signage Display Digital signage flat panel 125.7 cm (49.5") LCD Wi-Fi 500 cd/m² 4K Ultra HD Black Built-in processor Android 24/7
iiyama LH5075UHS-B2AG, Digital signage flat panel, 125.7 cm (49.5"), LCD, 3840 x 2160 pixels, Wi-Fi, 24/7
Availability:: Arriving soon
Choose non-stop high performance and reliability with the ideal all-in-one signage solution for mission critical environments. The LH5075UHS from iiyama can be operated in landscape or portrait orientation in continual around the clock environments, 24/7 without any interruption. Its versatility can be adapted to your industry’s display needs. On-board Android 11 OS means you can easily customize the display to your needs and install applications directly to it. The on-board iiSignage² (Content Management System) gives you total control of your messaging and advertising remotely and safely. The SDM Slot provides embedded PC option for total flexibility, security and control, while the FailOver feature ensures your content is always actively displayed through your choice of inputs. The built-in (and removable) WiFi module means this series is ready for remote content delivery using your network. Now the display is also offering DP-Out from any input. With iiControl (DMS), iiShare and the integrated EShare app (wireless screen sharing) you bring effortless ideation and efficient collaboration in your enterprise or school. You can start sharing wirelessly easier than ever before.
| Display | |
|---|---|
| Panel type | VA |
| Display diagonal | 49.5 |
| Display technology | LCD |
| Display resolution | 3840 x 2160 |
| Display brightness | 500 |
| HD type | 4K Ultra HD |
| Touchscreen | N |
| Native aspect ratio | 16:9 |
| Response time | 9.5 |
| Contrast ratio (typical) | 5000:1 |
| Viewing angle, horizontal | 178 |
| Viewing angle, vertical | 178 |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.285 x 0.285 |
| Active display area (W x H) | 1095.8 x 616.4 |
| Display diagonal (metric) | 125.7 |
| Maximum frame rate | 60 |
| Horizontal scan range | 28 - 160 |
| Native refresh rate | 60 |
| Haze rate | 25 |
| RGB colour space | sRGB |
| Ports & interfaces | |
| HDMI ports quantity | 3 |
| HDMI version | 2.0 |
| HDMI input ports quantity | 3 |
| DisplayPorts quantity | 1 |
| DisplayPorts in | 1 |
| DisplayPorts out | 1 |
| DisplayPort version | 1.2 |
| USB port | Y |
| USB ports quantity | 2 |
| USB version | 2.0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Audio (L/R) out | 1 |
| RS-232C | Y |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
| Card reader integrated | Y |
| Compatible memory cards | MicroSD (TransFlash) |
| Audio Return Channel (ARC) | Y |
| Audio | |
| Built-in speaker(s) | Y |
| Number of built-in speakers | 2 |
| RMS rated power | 20 |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| VESA mounting | Y |
| Panel mounting interface | 400 x 400 |
| Bezel width (bottom) | 13.5 |
| Bezel width (side) | 13.25 |
| Bezel width (top) | 13.5 |
| Bezel colour | Black |
| Anti-glare screen | Y |
| Performance | |
| Purpose | Universal |
| On Screen Display (OSD) | Y |
| Number of OSD languages | 15 |
| On Screen Display (OSD) languages | CHI (SIMPL),CZE,DAN,DEU,DUT,ENG,ESP,FIN,FRE,ITA,JPN,POL,RUS,SWE |
| Operating hours (hours/days) | 24/7 |
| HDCP | Y |
| HDCP version | 2.2 |
| Mean time between failures (MTBF) | 44000 |
| Power | |
| Power consumption (typical) | 112 |
| Power consumption (standby) | 0.4 |
| Power consumption (off) | 0.3 |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 110 |
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| Energy efficiency scale | A to G |
| Computer system | |
| Built-in processor | Y |
| Processor manufacturer | ARM |
| Processor family | ARM Cortex |
| Processor architecture | ARM Cortex-A73 |
| Processor cores | 4 |
| Internal memory | 4 |
| On-board graphics card model | ARM Mali-G52 |
| Internal storage capacity | 32 |
| Operating system installed | Android |
| Operating system version | 11 |
| Weight & dimensions | |
| Display width | 1122.7 |
| Display depth | 55 |
| Display height | 643.6 |
| Display weight | 11800 |
| Packaging data | |
| Package width | 1261 |
| Package depth | 1261 |
| Package height | 761 |
| Package weight | 16200 |
| Packaging content | |
| Remote control included | Y |
| Batteries included | Y |
| Cables included | AC,HDMI,RS-232 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 60 |
| Certificates | |
| Certification | CB, CE, TÜV-Bauart, EAC, ErP, WEEE, REACH |
| Logistics data | |
| Harmonized System (HS) code | 85285210 |
| Network | |
| Ethernet LAN | Y |
| Wi-Fi | Y |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Technical details | |
| Compliance certificates | RoHS |
| Other features | |
| Quick start guide | Y |
| Power supply type | Internal |
| Housing material | Metal |
