ASUS ROG -STRIX-850P-GAMING power supply unit 850 W 20+4 pin ATX ATX Black
ASUS ROG -STRIX-850P-GAMING, 850 W, 100 - 240 V, Active, 130 W, 850 W, 130 W
Availability: In Stock
Superior Stability. Next-Level EfficiencyThe ROG Strix Platinum PSU delivers the top-tier performance and unwavering stability demanded by gamers. Featuring next-gen GaN MOSFET for superior power efficiency. The Intelligent Voltage Stabilizer ensures a steady flow of power to the graphics card. Plus, it is ready for latest hardwares with ATX 3.1 compliance and a native 12V-2x6 connector. The ROG Strix Platinum Series ensures your high-end rig has the power to conquer any challenge.GaN MOSFETThe ROG Strix Platinum PSU boasts innovative GaN MOSFET that delivers superior power efficiency by up to 30%, resulting in lower energy waste. Plus, the smaller size of GaN MOSFET allows for a more organized internal layout within the PSU. This optimized design provides space for larger heatsinks and enhanced airflow, improving heat dissipation within the PSU.ROG HeatsinksCool under pressureROG heatsinks facilitate lower temperatures, longer component lifespan, and extended 0dB operation.Etched CablesMade from a pliable premium material, these etched cables are easily flexible during installation, and they operate at temperatures 50°C lower than the safety limit when routed for cable management. These cables also meet the rigorous standards of the UL1581 flame test and UL758 certification, helping to ensure a smooth PC DIY experience and exceptional safety.
| Power | |
|---|---|
| Total power | 850 |
| AC input voltage | 100 - 240 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 130 |
| Combined power (+12V) | 850 |
| Combined power (+5V) | 130 |
| Combined power (-12V) | 3.6 |
| Combined power (+5Vsb) | 15 |
| Max output current (+3.3V) | 25 |
| Max output current (+12V) | 70.8 |
| Max output current (+5V) | 25 |
| Max output current (-12V) | 0.3 |
| Max output current (+5Vsb) | 3 |
| Power protection features | Over current,Over power,Over voltage,Overheating,Short circuit,Under voltage |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 610 |
| Number of SATA power connectors | 6 |
| SATA power cable length | 400,120 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| Peripheral (Molex) power cable length | 400,150 |
| PCI Express power connectors (6+2 pin) | 3 |
| PCI Express power connectors (16-pin) | 1 |
| PCI Express power cable length | 750 |
| CPU power connector (4+4 pin) | Y |
| CPU power cable length | 1000 |
| Cabling type | Fully-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Platinum |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.1 |
| Silent mode | Y |
| Mean time between failures (MTBF) | 120000 |
| Design | |
| Product colour | Black |
| Cooling type | Semi-passive |
| Number of fans | 1 |
| Fan location | Top |
| Packaging content | |
| Cables included | CPU,PCIe,SATA,Peripheral (Molex) |
| Certificates | |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Width | 160 |
| Depth | 150 |
| Height | 86 |
| Weight | 1780 |
| Packaging data | |
| Package width | 320 |
| Package depth | 200 |
| Package height | 108 |
| Package weight | 2800 |
| Package type | Box |
