Zyxel CX4800-56F Managed L3 1U Black
Zyxel CX4800-56F, Managed, L3, Rack mounting, 1U
Availability: In Stock
Future Proof Aggregation & Core SwitchThe CX4800-56F supports a full suite of Layer 2 features, including VLAN, ACL, port aggregation, and 802.1X, to enhance security by preventing unauthorized access to cloud resources and AI workloads, optimize bandwidth for high-speed GPU data transfers, and enable dynamic, isolated workload environments in large-scale AI and cloud deployments.Nebula, The Intelligent Cloud ManagementNebula offers comprehensive monitoring and reporting capabilities, including real-time notifications for critical events via email or the mobile app. With Nebula, you can enjoy a streamlined experience for network installation and management without the need for additional costs for software or hardware controllers.Dedicated Networked AV ModeThe CX4800-56F features a custom-designed networked AV mode for standalone operation. It supports 10G Ethernet with pixel-perfect 4K60 video streaming in real-time, making it ideal for applications ranging from live events to XR and medical imaging. Leveraging AI intelligence, the switch simplifies the setup process by automatically configuring all necessary parameters, enabling a professional AVoIP deployment within minutes.
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| Cloud-managed | Y |
| ARP inspection | Y |
| Configuring Location Settings (CLI) | Y |
| System event log | Y |
| MIB support | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports type | N |
| USB Type-A ports quantity | 2 |
| Number of management ports | 1 |
| Console port | RJ-45 |
| QSFP28 ports quantity | 8 |
| SFP28 ports quantity | 48 |
| Power connector | AC/DC |
| Network | |
| 10G support | Y |
| Port mirroring | Y |
| Policy-based routing | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Spanning tree protocol | Y |
| VLAN support | Y |
| Data transmission | |
| Switching capacity | 4000 |
| MAC address table | 30000 |
| Static route | Y |
| Jumbo frames support | Y |
| Jumbo frames | 9000 |
| Packet buffer memory | 32 |
| Security | |
| DHCP features | DHCP relay,DHCP server,DHCP snooping |
| Access Control List (ACL) | Y |
| IGMP snooping | Y |
| Security algorithms | SSH-2,SSL/TLS |
| MAC address filtering | Y |
| SSH/SSL support | Y |
| Loop protection | Y |
| Multicast features | |
| Multicast support | Y |
| Design | |
| Rack mounting | Y |
| Form factor | 1U |
| Product colour | Black |
| Reset button | Y |
| LED indicators | Y |
| Performance | |
| Memory type | RAM / Flash |
| Internal memory | 8000 |
| Flash memory | 64 |
| Mean time between failures (MTBF) | 5900181.1 |
| Power | |
| Power source | AC/DC |
| Power supply included | Y |
| Number of power supply units | 2 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | N |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 70 |
| Operating relative humidity (H-H) | 10 - 95 |
| Storage relative humidity (H-H) | 10 - 95 |
| Heat dissipation | 1122 |
| Weight & dimensions | |
| Width | 440 |
| Depth | 489 |
| Height | 45 |
| Weight | 8620 |
| Packaging content | |
| Cables included | AC |
| Rack mount kit | Y |
| Packaging data | |
| Package type | Box |
| Package width | 595 |
| Package depth | 706 |
| Package height | 206 |
| Logistics data | |
| Country of origin | Taiwan |
