Zyxel POE12-3PD-ZZ0101F PoE adapter Gigabit Ethernet
Zyxel POE12-3PD-ZZ0101F, Gigabit Ethernet, 1000 Mbit/s, 10/100/1000, IEEE 802.3at, IEEE 802.3bt, Full, Cat5, Cat5e, Cat6, Cat6+, Cat6a, Cat6e, Cat7, Cat7e
Availability: In Stock
The PoE12-3PD is a Gigabit PoE Extender designed for point to multipoint PoE applications, which effortlessly extend the range of power and data connectivity when your devices are located at a distance that far away from power source or connection to a PoE Switch. It features four RJ-45 Gigabit Ethernet ports, offering one (1) PoE++ PoE input port with up to 60W power input and three PoE output to your devices. Instead of connecting to an AC adapter, connecting via a PoE switch enables better visibility for network management to cover the edge of your network. It features three PoE+ ports to power a variety of PoE devices, including IP cameras, VoIP handsets, IoT device, Sensors, PoE switches and wireless access points. PoE12-3PD is good for residential and commercial network environment
| Network | |
|---|---|
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 1000 |
| Cabling technology | 10/100/1000 |
| Power over Ethernet (PoE) | Y |
| Networking standards | IEEE 802.3at,IEEE 802.3bt |
| Auto MDI/MDI-X | Y |
| Duplex system | Full |
| Cable types supported | Cat5,Cat5e,Cat6,Cat6+,Cat6a,Cat6e,Cat7,Cat7e |
| Web-based management | Y |
| Firmware upgradeable | Y |
| Syslog | N |
| Forwarding rate | 8000 |
| MAC address table | 2000 |
| Packet buffer memory | 128 |
| Transmission method | tcp |
| Supported network protocols | ip |
| Certificates | |
| Compliance certificates | BSMI,CE,EAC,Electromagnetic Compatibility (EMC),Federal Communications Commission (FCC),Low Voltage Directive (LVD),RoHS |
| Compliance industry standards | • IEEE802.3 10Base-T Ethernet • IEEE 802.3u 100Base-Tx Ethernet • IEEE 802.3ab 1000Base-T Ethernet • IEEE 802.3z 1000 Base-X • IEEE 802.3x flow control • IEEE 802.3af PoE • IEEE 802.3at PoE plus • IEEE 802.3bt (60 W) PoE over 4 pair |
| Operational conditions | |
| Operating temperature (T-T) | -4 - 122 |
| Operating relative humidity (H-H) | 10 - 95 |
| Storage temperature (T-T) | -40 - 70 |
| Storage relative humidity (H-H) | 10 - 95 |
| Weight & dimensions | |
| Width | 180 |
| Depth | 99 |
| Height | 36 |
| Weight | 257 |
| Packaging content | |
| Number of products included | 24 |
| Wall mounting kit | Y |
| AC adapter included | N |
| Power cord included | N |
| Quick installation guide | Y |
| Manual | N |
| Packaging content | • PoE extender • Safety warning and doc |
| Packaging data | |
| Package length | 214 |
| Package width | 125 |
| Package depth | 47 |
| Package weight | 114 |
| Package volume | 1257 |
| Package type | Box |
| Logistics data | |
| Master (outer) cases per pallet (air) | 42 |
| Products per pallet (air) | 1008 |
| Pallet gross length | 1220 |
| Pallet gross width | 1040 |
| Pallet height (air) | 1863 |
| Pallet gross weight (sea) | 43153 |
| Master (outer) cases per pallet (sea) | 42 |
| Products per pallet (sea) | 1008 |
| Pallet height (sea) | 1863 |
| Customs product code (TARIC) | 85176200 |
| Shipping (inner) case gross weight | 43153 |
| Warranty period | 2 |
| Master (outer) case width | 370 |
| Master (outer) case length | 391 |
| Master (outer) case height | 247 |
| Master (outer) case gross weight | 9560 |
