GIGABYTE B760M DS3H WIFI6E GEN5 Motherboard - Supports Intel Core 14th Gen CPUs, 6+2+1 Phases Digital VRM, up to 5600MHz DDR5, 2xPCIe 4.0 M.2, Wi-Fi 6E, 2.5GbE LAN, USB 3.2 Gen2
(0 review)Add your review
€106,08

GIGABYTE B760M DS3H WIFI6E GEN5 Motherboard - Supports Intel Core 14th Gen CPUs, 6+2+1 Phases Digital VRM, up to 5600MHz DDR5, 2xPCIe 4.0 M.2, Wi-Fi 6E, 2.5GbE LAN, USB 3.2 Gen2, Intel, LGA 1700, Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel..., LGA 1700, DDR5-SDRAM, 256 GB

Availability:: Arriving soon
-
+
Add to Cart
Add to wishlist
Compare
Share
EAN:4719331872809Categories:Hardware Components

Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge technology.

Processor
Processor manufacturerIntel
Processor socketLGA 1700
Compatible processor seriesIntel Celeron,Intel Core i3 12th Gen,Intel Core i3 13th Gen,Intel Core i3 14th Gen,Intel Core i5 12th Gen,Intel Core i5 13th Gen,Intel Core i5 14th Gen,Intel Core i7 12th Gen,Intel Core i7 13th Gen,Intel Core i7 14th Gen,Intel Core i9 12th Gen,Intel Core i9 13th Gen,Intel Core i9 14th Gen,Intel Pentium Gold
Supported processor socketsLGA 1700
Memory
Supported memory typesDDR5-SDRAM
Number of memory slots4
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilityECC & non-ECC
Supported memory clock speeds5600,5200,4800,4400
Supported memory clock speed (max)5600
Maximum internal memory256
Unbuffered memoryY
Maximum internal memory per slot64
Storage controllers
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2,PCI Express 4.0,SATA III
Number of HDDs supported4
Number of storage drives supported6
RAID supportY
RAID levels0,1,5,10
Graphics
Parallel processing technology supportNot supported
Maximum resolution4096 x 2304
HDCPY
DirectX version12.0
Internal I/O
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Number of SATA III connectors4
S/PDIF out connectorY
Front panel audio connectorY
Front panel connectorY
ATX Power connector (24-pin)Y
CPU fan connectorY
Number of CPU fan connectors1
Number of chassis fan connectors3
EPS power connector (8-pin)Y
Number of EPS power connectors (8-pin)1
TPM connectorY
12V power connectorY
RGB LED pin headerY
Number of RGB LED pin headers3
Rear panel I/O ports
USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
Ethernet LAN (RJ-45) ports1
PS/2 ports quantity1
HDMI ports quantity1
HDMI version2.1
DisplayPorts quantity2
DisplayPort version1.2
Headphone outputs1
Line-inY
Microphone inY
WiFi-AP antenna jack2
Network
Ethernet LANY
Ethernet interface type2.5 Gigabit Ethernet
LAN controllerRealtek RTL8125
Wi-FiY
Top Wi-Fi standardWi-Fi 6E (802.11ax)
Wi-Fi standards802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax),Wi-Fi 6E (802.11ax)
WLAN controller modelIntel Wi-Fi 6E AX210
BluetoothY
Bluetooth version5.3
Features
Motherboard chipsetIntel B760 Express
Audio chipRealtek ALC897
Audio output channels7.1
Product colourDark brown
PC health monitoringFAN,Temperature,Voltage,Water cooling
Component forPC
Motherboard form factorMicro ATX
Motherboard chipset familyIntel
Cooling typePassive
Power source typeATX
Windows operating systems supportedWindows 10 x64,Windows 11 x64
Expansion slots
PCI Express x1 (Gen 3.x) slots2
PCI Express x16 (Gen 5.x) slots1
Number of M.2 (M) slots2
1st M.2 largest key size2280
1st M.2 highest PCI Express generation4.0
2nd M.2 largest key size2280
2nd M.2 highest PCI Express generation4.0
BIOS
BIOS typeUEFI AMI
BIOS memory size128
ACPI version5.0
Clear CMOS jumperY
Desktop Management Interface (DMI) version2.7
System Management BIOS (SMBIOS) version2.7
Logistics data
Country of originChina
Products per shipping (inner) case1
Battery
Battery weight3
Lithium weight per battery0.07
Number of battery cells1
Battery technologyLithium-Manganese Dioxide (LiMnO2)
Battery typeCR2032
Packaging data
Package width270
Package depth268
Package height68
Package weight1200
Weight & dimensions
Width244
Depth244
Height35
Packaging content
Batteries includedY
Antenna includedY
Screws includedY
Bundled softwareNorton® Internet Security (OEM version)
Other features
Weight1100
Technical details
Warranty period3
