StarTech.com 2-Port PCI Express Serial Card, Dual Port PCIe to RS232 (DB9) Serial Card, 16C1050 UART, Standard or Low Profile Brackets, COM Retention, For Windows & Linux
(0 review)Add your review
€55,84

StarTech.com 2-Port PCI Express Serial Card, Dual Port PCIe to RS232 (DB9) Serial Card, 16C1050 UART, Standard or Low Profile Brackets, COM Retention, For Windows & Linux, PCIe, Serial, Full-height / Low-profile, PCI 2.0, RS-232, Yellow

Availability: In Stock
EAN:0065030894760Categories:NetworkingTags:

Baud Rate 921.6 Kbps per Port | 256-byte FIFO | PCIe 2.0 x1Add serial communication support to your desktop computer or Small Form Factor (SFF) system, using this two-port serial card. RS-232 (DB9) support enables control and communication with a serial peripheral device.Legacy ConnectivityInstall this card to enable the continued use of legacy serial devices, preventing down time and avoiding costly upgrades. The 2-port PCIe serial card is ideal for system upgrades in a wide range of applications for logistics, manufacturing, and freight sectors, and the IT industry, such as POS equipment, security systems, A/V installations, and more.Connect with EaseThe RS-232 card features dual ports with 16C1050 UART support, 256-byte FIFO (transmit/receive), bi-directional speeds up to 921.6 Kbps per port, low-profile brackets are included for SFF systems, and serial port LED status lights. In addition, it supports Windows and Linux systems for maximum compatibility.21050-PC-SERIAL-CARD is backed for 2-years by StarTech.com, including free lifetime 24/5 multi-lingual technical assistance.The StarTech.com Advantage

Ports & interfaces
Host interfacePCIe
Output interfaceSerial
Expansion card form factorFull-height / Low-profile
Expansion card standardPCI 2.0
Serial ports quantity2
Serial interface typeRS-232
Design
InternalY
Product colourYellow
LED indicatorsActivity
Features
ChipsetASIX - AX99100, ASIX - ZT3243LFEY
Baud rate921.6
FIFO (First In, First Out)256
Data bits5,6,7,8,9
Flow control supportY
Parity bitEven,Mark,N,Odd,Space
Operational conditions
Operating temperature (T-T)0 - 55
Storage temperature (T-T)-40 - 75
Operating relative humidity (H-H)5 - 95
System requirements
Windows operating systems supportedWindows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 11,Windows 11 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64
Linux operating systems supportedY
Server operating systems supportedWindows Server 2016,Windows Server 2019
Technical details
Compliance certificatesCE,RoHS
Weight & dimensions
Width65
Depth67
Height18
Weight51
Packaging data
Mounting brackets includedY
Quick installation guideY
Package width207
Package depth144
Package height38
Package weight200
Logistics data
Harmonized System (HS) code84733020
Products per master (outer) case50
Master (outer) case width530
Master (outer) case length440
Master (outer) case height340
