Conceptronic 4-Port 100W GaN USB PD Charger with USB-C Charging Cable, USB-C x 3, USB-A x 1, QC 3.0, PPS
Conceptronic 4-Port 100W GaN USB PD Charger with USB-C Charging Cable, USB-C x 3, USB-A x 1, QC 3.0, PPS, Indoor, AC, 20 V, 1.5 m, Black
Availability:: Arriving soon
This charger features cutting-edge Gallium Nitride (GaN) technology, delivering up to 100W of power for exceptionally fast and efficient charging. It includes 4 ports: 3 USB-C ports with Power Delivery (PD) 3.0 and 1 USB-A port with Quick Charge (QC) 3.0, enabling simultaneous charging of multiple devices with varying power needs. The charger supports a wide range of output options from 3.3V to 20.0V, making it compatible with a broad spectrum of devices, from smartphones to laptops. Enhanced safety is ensured with built-in protections against overload, short-circuiting, and overheating, safeguarding both the charger and connected devices. It incorporates USB Power Delivery (PD) 3.0 and Quick Charge (QC) 3.0 technologies for rapid charging, and features Programmable Power Supply (PPS) compliance to optimize charging efficiency and reduce heat generation. Additionally, the charger includes a 1.5m 100W USB-C to USB-C cable equipped with an E-mark chip for added convenience and versatility. (Note: A charging cable with an E-mark chip is required for power delivery greater than 3 amps.)
| Performance | |
|---|---|
| Charger compatibility | Universal |
| Power source type | AC |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB Type-C ports quantity | 3 |
| Fast charging | Y |
| Fast charging technology | Power Delivery 3.0,Quick Charge 3.0 |
| Charger type | Indoor |
| Number of simultaneously connected devices (max) | 4 |
| USB Power Delivery (USB PD) | Y |
| USB Power Delivery revision | 3.0 |
| Power protection features | Overheating,Overload,Short circuit |
| Design | |
| Product colour | Black |
| Cable length | 1.5 m |
| Gallium nitride (GaN) transistors | Y |
| Power | |
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
| Input current | 2.5 A |
| Maximum power | 100 W |
| Maximum output voltage | 20 V |
| Minimum output voltage | 3.3 V |
| Output current (5V) | 3 A |
| Output current (9V) | 3 A |
| Output current (12V) | 3 A |
| Output current (15V) | 3 A |
| Output current (20V) | 5 A |
| Weight & dimensions | |
| Width | 65 mm |
| Depth | 65 mm |
| Height | 32 mm |
| Weight | 204 g |
| Packaging data | |
| Package width | 153 mm |
| Package depth | 36 mm |
| Package height | 136 mm |
| Package weight | 136 g |
| Package type | Box |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -20 - 80 °C |
| Operating relative humidity (H-H) | 20 - 80 % |
| Storage relative humidity (H-H) | 10 - 90 % |
| Packaging content | |
| Cables included | USB Type-C |
| Manual | Y |
| Sustainability | |
| Sustainability compliance | Y |
| Logistics data | |
| Harmonized System (HS) code | 8504408390 |
| Pallet gross width | 1200 mm |
| Pallet gross length | 800 mm |
| Pallet gross height | 1480 mm |
| Master (outer) case width | 385 mm |
| Master (outer) case length | 292 mm |
| Master (outer) case height | 320 mm |
| Master (outer) case gross weight | 12600 g |
| Products per master (outer) case | 40 pc(s) |
| Country of origin | China |
