Vaddio RoboSHOT 30E SDI 8.57 MP White 1920 x 1080 pixels 60 fps CMOS 25.4 / 2.5 mm (1 / 2.5")
Vaddio RoboSHOT 30E SDI, 8.57 MP, CMOS, Full HD, 1920 x 1080 pixels, 60 fps, White
Availability:: Arriving soon
Professional A/V presentation camera. Simultaneous HDMI, 3Gb/s HD-SDI, and IP (H.264) streaming. Recommended for large meeting rooms, lecture halls, and houses of worship.Introducing the RoboSHOT Elite Series – Vaddio’s next generation of professional cameras. Designed with an 1/2.5-type Exmor R CMOS sensor, RoboSHOT Elite cameras deliver striking, high-definition video image quality. Cutting-edge image signal processing (ISP) results in better light-gathering capabilities, incredible contrast and sharp 1080p/60 video, even in dim lighting conditions.RoboSHOT Elite cameras are equipped with enhanced wide dynamic range, which can help correct for environments with uneven lighting by making darker or over-bright areas in video more visible and detailed.Enjoy IP streaming (RTSP or RTMP format with H.264 compression) to share live events like church services, lectures, or meetings over popular applications like YouTube, Livestream and Facebook.A web-based user interface gives the user camera control with a web browser from anywhere in the world over the IP network. To watch the IP stream, simply enter the camera’s streaming URL into any standards based (H.264, RTSP format) media player. Perfect for remote management, network operating centers and overall IT control.The RoboSHOT 30E cameras have a 20x optical zoom and have an additional 10x of IntelliZoomTM Image Processing. IntelliZoom image processing technology lets you zoom greater distances without compromising any resolution quality of the image. Most digital zooms use electronic cropping to get closer to the subject, resulting in fuzzy images. The RoboSHOT 30E camera’s powerful processor compares patterns found in adjacent pixels and creates new pixels to match selected patterns, resulting in more realistic, higher-quality images.The Elite Series of RoboSHOT PTZ cameras is equipped with Vaddio’s industry-leading Tri-Synchronous Motion technology allowing all three axes of the camera to move simultaneously for ultra-smooth, natural camera motion.The RoboSHOT 30E cameras are ideal for larger spaces such as large meeting rooms, lecture halls, conference centers, and houses of worship.Video outputs include simultaneous 3G-SDI, HDMI and IP (H.264) streaming.This Package Includes:- RoboSHOT 30E SDI camera (black or white)- Quick-Start Guide- PoE+ Midspan Power Injector- Thin Profile Wall Mount (black or white) with mounting hardware and installation manual- Vaddio IR Remote Commander- EZCamera RS-232 Control Adapter
| Camera | |
|---|---|
| Megapixel (approx.) | 8.57 |
| Sensor type | CMOS |
| Optical sensor size | 1/2.5 |
| Effective sensor resolution | 8.51 |
| Combined zoom | 30 |
| Horizontal field of view (wide) | 70.2 |
| Horizontal field of view (tele) | 4.1 |
| Minimum illumination | 1 |
| White balance | Auto,Manual,One push |
| Focus adjustment | Auto/Manual |
| Number of camera presets | 16 |
| Gain control type | Auto/Manual |
| PTZ control | Y |
| Video | |
| HD type | Full HD |
| Maximum video resolution | 1920 x 1080 |
| Maximum frame rate | 60 |
| Supported video modes | 1080p |
| Video formats supported | H.264 |
| Design | |
| Product colour | White |
| Mounting type | Stand |
| Tilt angle range | -30 - 90 |
| Pan range | -160 - 160 |
| Web-based management | Y |
| Tilt speed (min) | 0.35 |
| Tilt speed (max) | 120 |
| Pan speed (min) | 0.35 |
| Pan speed (max) | 120 |
| Ports & interfaces | |
| HDMI ports quantity | 1 |
| RS-232 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| 3G-SDI output | Y |
| Power | |
| Power source type | PoE |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Packaging content | |
| Quick start guide | Y |
| Mounting kit | Y |
| Network | |
| Network streaming | Y |
| Logistics data | |
| Harmonized System (HS) code | 85258900 |
| Weight & dimensions | |
| Width | 179.1 |
| Depth | 171.5 |
| Height | 176.3 |
| Weight | 2200 |
