LevelOne SFP-6601 network transceiver module Copper 10000 Mbit/s SFP+
LevelOne SFP-6601, Copper, 10000 Mbit/s, SFP+, 100 m, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Gigabit Ethernet, IEEE 802.3, IEEE 802.3an, IEEE 802.3az
Availability:: Arriving soon
The LevelOne SFP-6601 is the latest generation of 10Gbps copper SFP+ transceivers. It provides a powerful duplex data link for bidirectional communication over copper Ethernet cables. The SFP-6601 transmits data from 10GBase-T copper to SFP fiber optic interfaces at up to 10 Gbps and a maximum cable length of up to 30 meters over Category 6a, 7 and 8 twisted pair cables. Ideal for servers and storage systems requiring high bandwidths. The SFP-6601 offers system developers and planners a high degree of flexibility.
| Performance | |
|---|---|
| SFP transceiver type | Copper |
| Maximum data transfer rate | 10000 |
| Interface type | SFP+ |
| Maximum transfer distance | 100 |
| Ethernet interface type | 2.5 Gigabit Ethernet,5 Gigabit Ethernet,10 Gigabit Ethernet,Gigabit Ethernet |
| Networking standards | IEEE 802.3,IEEE 802.3an,IEEE 802.3az |
| Copper ethernet cabling technology | 10GBASE,1000BASE |
| Features | |
| Product colour | Silver |
| Hot-swap | Y |
| Power | |
| Maximum voltage | 3.3 |
| Maximum current | 0.7 |
| Power consumption (typical) | 1.05 |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | CE |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 60 |
| Storage temperature (T-T) | -40 - 85 |
| Operating relative humidity (H-H) | 0 - 95 |
| Storage relative humidity (H-H) | 0 - 95 |
| Weight & dimensions | |
| Width | 67 |
| Depth | 8.5 |
| Height | 13.4 |
| Weight | 20 |
| Packaging data | |
| User guide | Y |
| Logistics data | |
| Harmonized System (HS) code | 85369010 |
