LevelOne 15dBi 5GHz Directional Dual-Polarization Panel Antenna, Indoor/Outdoor
LevelOne 15dBi 5GHz Directional Dual-Polarization Panel Antenna, Indoor/Outdoor, 15 dBi, 5.1 ~ 5.9 GHz, IEEE 802.11a, IEEE 802.11n, 50 Ω, 22°, 15°
Availability: In Stock
The LevelOne WAN-9151 is a directional, dual-polarization antenna that can be mounted either indoors or outside. Dual-polarization offers the flexibility of two different communication channels receiving simultaneously, while a high gain of 15dBi offers better range and signal strength. If mounted outdoors the IP65-rated weatherproof housing can withstand temperatures from minus 30°C up to 60°C, as well as rain, snow, dust and other harsh conditions. - Provides 15dBi directional operation- Directional operation provides extended point to point coverage- For IEEE 802.11a/n Wireless applications in 5 GHz frequency range- Dual-Polarization to avoid interference- Low wind loading
| Performance | |
|---|---|
| Frequency band | 5.1 ~ 5.9 |
| Networking standards | IEEE 802.11a,IEEE 802.11n |
| Impedance | 50 |
| Horizontal beam width | 22 |
| Vertical beam width | 15 |
| Antenna gain level (max) | 15 |
| Features | |
| Antenna type | Directional antenna |
| Antenna connector type | N-type |
| Polarization | Dual polarization |
| Voltage Standing Wave Ratio (VSWR) | 2.0 |
| Product colour | Grey |
| Protection features | Dust resistant,Snow resistant,Water resistant |
| Survival wind speed | 180 |
| Purpose | Indoor & outdoor |
| Maximum cable loss with connectors | -10 |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 60 |
| Operating relative humidity (H-H) | 0 - 95 |
| Weight & dimensions | |
| Width | 137.5 |
| Depth | 162.5 |
| Height | 16 |
| Weight | 208 |
| Packaging data | |
| Package width | 161 |
| Package depth | 218 |
| Package height | 74 |
| Package weight | 726 |
| Package type | Box |
| Packaging content | |
| Mounting kit | Y |
| Quick installation guide | Y |
| Logistics data | |
| Harmonized System (HS) code | 85177100 |
| Country of origin | Taiwan |
| Master (outer) case width | 370 |
| Master (outer) case length | 450 |
| Master (outer) case height | 340 |
| Master (outer) case gross weight | 15500 |
| Products per master (outer) case | 20 |
