LevelOne OSW-1031 network switch Unmanaged 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) Black
LevelOne OSW-1031, Unmanaged, 2.5G Ethernet (100/1000/2500), Full duplex, Power over Ethernet (PoE)
Availability: In Stock
The OSW-1031 is 8-Port Gigabit Ethernet Unmanaged PoE Switch, with 2 Gigabit RJ45 and 2 Gigabit SFP Uplink ports. also offers powerful DIP switch button configuration for PoE Auto-Check / VLAN mode features.The OSW-1031 PoE-enabled switches features an IEEE 802.3af/at certified, better PoE functionality with 115W PoE power budget and usability. supports up to 8 ports at 15.4/30W. Giving you flexibility in power allocation for a variety of powered devices enabling you to scale your operations to meet business growth, operational cost savings, and ease of management.The OSW-1031 switch is designed to withstand outdoor or harsh environments, and can be mounted on a wall, pole, or cabinet to fit your space and layout. Whether you need to connect your devices in a garden, pool, or patio area, this switch will provide you with reliable and efficient data transmission. Don't miss this opportunity to upgrade your network with this powerful and versatile switch.
| Management features | |
|---|---|
| Switch type | Unmanaged |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| 2.5G Ethernet (copper) ports quantity | 8 |
| SFP+ module slots quantity | 2 |
| Power connector | DC-in jack |
| Network | |
| Networking standards | IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u,IEEE 802.3z |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T,1000BASE-X |
| Full duplex | Y |
| Half duplex | Y |
| Flow control support | Y |
| Auto MDI/MDI-X | Y |
| Ethernet LAN data rates | 1000 |
| Auto-negotiation | Y |
| Data transmission | |
| Switching capacity | 20 |
| MAC address table | 4000 |
| Jumbo frames support | Y |
| Jumbo frames | 9000 |
| Packet buffer memory | 12 |
| Design | |
| Rack mounting | N |
| Stackable | N |
| Product colour | Black |
| LED indicators | Link,Power |
| International Protection (IP) code | IP55 |
| Performance | |
| Fanless | N |
| Mean time between failures (MTBF) | 4000000 |
| Power | |
| Power source | AC |
| Power supply included | Y |
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| Power consumption (max) | 120 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 115 |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 65 |
| Storage temperature (T-T) | -40 - 75 |
| Operating relative humidity (H-H) | 0 - 90 |
| Storage relative humidity (H-H) | 0 - 90 |
| Weight & dimensions | |
| Width | 280 |
| Depth | 200 |
| Height | 250 |
| Weight | 8000 |
| Packaging content | |
| Quick start guide | Y |
| Manual | Y |
| Packaging data | |
| Package type | Box |
| Certificates | |
| Compliance certificates | CE,Federal Communications Commission (FCC) |
