MSI B760 GAMING PLUS WIFI motherboard Intel B760 LGA 1700 ATX
(0 review)Add your review
€126,97

MSI B760 GAMING PLUS WIFI, Intel, LGA 1700, Intel® Celeron®, Intel® Pentium® Gold, DDR5-SDRAM, 192 GB, DIMM

Availability:: Arriving soon
EAN:4711377086561Categories:Hardware Components

B760 GAMING PLUS WIFI is designed with tons of connectivity, flexible tools, and convenient Wi-Fi solution with DDR5 memory version for gamers who want all.Extended HeatsinkExtended Heatsink enlarges the surface of heat dissipation and maintain the performance at heavy loads.M.2 Shield FrozrStrengthened M.2 thermal solution helps M.2 SSD safe and ensures incredible performance.Heavy Plated VRM HeatsinkThe VRM heatsink covers the upper MOS and helps dissipate the heat.7W/mK Thermal Pad & Additional Choke PadHigh-quality 7W/mK MOSFET thermal pads and additional choke thermal pads ensure stable performance when all cores are running at high speed.Chipset HeatsinkThe chipset heatsink is designed to reduce dust and noise and also capable of maintaining high efficiency of PCH.12+1+1 DUET RAIL POWER SYSTEMUnleash and sustain the maximum performance with a VRM design built with a total of 12+1+1 power design. Combining dual power connectors and exclusive Core Boost technology, B760 GAMING PLUS WIFI is ready to sustain heavy daily work.EZ M.2 CLIPHave trouble turning screws? MSI innovative EZ M.2 clip assist you install an M.2 SSD quickly and effortlessly.MSI DRIVER UTILITY INSTALLEROnce connected to the internet, MSI Driver Utility Installer will detect and present suitable drivers and utilities automatically, you can download and install with just a few clicks.FAST AND FUTURE-READY STORAGEB760 GAMING PLUS WIFI motherboard supports all the latest storage standards, which allows users to connect any ultra-fast storage device. Start games faster, load levels faster and have a real advantage over your enemies.LATEST DDR5 MEMORY WITH SMT SLOTA huge step of DDR performance enhancement with the latest DDR5 memory. Combines with dedicated SMT welding process and MSI Memory Boost technology, B760 GAMING PLUS WIFI motherboards are ready to deliver the world class memory performance.CLICK BIOS 5Get more from a loaded BIOS designed for ease of use. Fine-tune the motherboard for gaming performance, efficiency, or overclocking world records!MSI CENTERMSI brand new MSI Center unifies a suite of MSI software utilities into a single centralized application. Take control of advanced motherboards features and unleash endless possibilities.EXCLUSIVE UI OF AIDA64 EXTREMEMSI motherboards provide 60 days free trial of AIDA64 Extreme - MSI edition. AIDA64 Extreme is an almighty application for system information, diagnostics and benchmarks. With the application, you can monitor the detailed hardware and software information on PC and save it to file in multiple formats such as CSV and HTML.OPT-IN TO CYBER SAFETY WITH NORTON 360 DELUXEMultiple layers of protection for your devices, online privacy features including our Secure VPN, plus Dark Web Monitoring - all in a single solution. With MSI motherboards, you can enjoy a 60-day free trial of Norton 360 Deluxe.RESIZABLE BARResizable BAR (Re-Size BAR) is an advanced PCI Express feature that enables the CPU to access the entire GPU frame buffer at once and improve performance.EXTEND YOUR RGB EXPERIENCE WITH EASEAdd more color if you want! Mystic Light Extension pin header provides an intuitive way to control additional RGB strips and other RGB peripherals added to a system, without needing a separate RGB controller.HIGH-BANDWIDTH AND LOW-LATENCY NETWORKMSI's premium network solution provides incredible data transfer speed for demanding users.

Processor
Processor manufacturerIntel
Processor socketLGA 1700
Compatible processor seriesIntel Celeron,Intel Pentium Gold
Memory
Supported memory typesDDR5-SDRAM
Number of memory slots4
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilitynon-ECC
Maximum internal memory192
Storage controllers
Supported storage drive interfacesM.2,SATA
RAID supportY
RAID levels0,1,5,10
Graphics
On-board graphics cardN
Internal I/O
USB 2.0 connectors4
USB 3.2 Gen 1 (3.1 Gen 1) connectors3
Number of SATA III connectors4
S/PDIF out connectorY
TPM connectorY
Rear panel I/O ports
USB 2.0 ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
HDMI version2.1
DisplayPorts quantity1
DisplayPort version1.4
S/PDIF out portY
Network
Ethernet LANY
Ethernet interface type2.5 Gigabit Ethernet
LAN controllerDragon RTL8125BG
Wi-FiY
Top Wi-Fi standardWi-Fi 6E (802.11ax)
BluetoothY
Bluetooth version5.3
Features
Motherboard chipsetIntel B760
Audio chipRealtek ALC897
Audio output channels7.1
Product colourBlack
Component forPC
Motherboard form factorATX
Motherboard chipset familyIntel
Windows operating systems supportedWindows 10 x64,Windows 11 x64
Expansion slots
PCI Express x1 slots3
PCI Express x1 (Gen 3.x) slots3
PCI Express x16 slots2
PCI Express x16 (Gen 4.x) slots2
Number of M.2 (M) slots2
Weight & dimensions
Width243.84
Depth304.8
