StarTech.com 4-Port Multi-Gigabit PoE++ Injector, 5/2.5/1G Ethernet (NBASE-T), PoE/PoE+/PoE++ (802.3af/802.3at/802.3bt), 160Watts Power Budget, Wall/DIN Rail Mountable, Unmanaged
(0 review)Add your review
€344,50

StarTech.com 4-Port Multi-Gigabit PoE++ Injector, 5/2.5/1G Ethernet (NBASE-T), PoE/PoE+/PoE++ (802.3af/802.3at/802.3bt), 160Watts Power Budget, Wall/DIN Rail Mountable, Unmanaged, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet, 10,100,1000,2500,5000 Mbit/s, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3i, IEEE 802.3u, Cat5e, Cat6, Cat6a, Microsemi - PD69208T4, Microsemi - PD69200R, Grey

Availability: In Stock
EAN:0065030900928Categories:NetworkingTags:

Supply power and data to up to four remote Powered Devices (PDs) with this PoE/PoE+/PoE++ injectorThis 4-Port Multi-Gigabit PoE++ Injector Hub serves as Power Sourcing Equipment (PSE) and enables multigigabit speeds of 5Gbps, 2.5Gbps, 1Gbps, 100Mbps, and 10Mbps across four Ethernet ports. This mid/end-span injector is capable of transmitting network data and power up to 328ft (100m) for remote installations. The PoE, PoE+, PoE++ compatibility and selectable power output ensure seamless compatibility with Powered Devices (PD). The TAA-compliant injector includes a Universal Power Adapter for different regions (NA/JP, EU, UK, and ANZ).Versatile PoE InjectorMultiport PoE Injector supports the IEEE 802.3af, 802.3at, and 802.3bt (Type 3 and Type 4) standards for Power Sourcing Equipment (PSE), delivering up to 52V DC and 95Watts. This flexibility eliminates the need for a separate power source for remote networked devices such as IP cameras, access control devices, remote kiosks (POSs), wireless access points, PoE lighting, and digital signage.Experience streamlined cable management with all network cables routed from one side of the unit for a clean and organized setup.Flexible Power OptionsTailor the power output to the specific needs of the device using the Power Output Switch. The options include 90W, 95W PoH, or legacy 60W (for UPoE/UPoE+) for all the ports on the PoE Injector Adapter.The Level-4 ESD protection (15kV air and 8kV contact) enhances device safety and reduces EMI for stable operation, minimizing the risk of downtime and hardware failures.Increased Network SpeedsThe unmanaged PoE Injector with NBASE-T technology provides access to an increased bandwidth up to 5Gbps, significantly reducing network slowdowns during data-intensive applications such as streaming high-definition video feeds, high-speed Internet, access local network resources, online or local network backups, and FTP access.The StarTech.com Advantage

Network
Ethernet interface type2.5 Gigabit Ethernet,5 Gigabit Ethernet,Fast Ethernet,Gigabit Ethernet
Ethernet LAN data rates10,100,1000,2500,5000
Power over Ethernet (PoE)Y
Networking standardsIEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt,IEEE 802.3i,IEEE 802.3u
Auto MDI/MDI-XY
Cable types supportedCat5e,Cat6,Cat6a
ChipsetMicrosemi - PD69208T4, Microsemi - PD69200R
Features
Product colourGrey
Housing materialMetal
Wall mountableY
Maximum operating distance100
LED indicatorsStatus
Jumbo frames supportY
Jumbo frames9000
Ports & interfaces
Ethernet LAN (RJ-45) ports8
RJ-45 input ports4
RJ-45 output ports4
DC-in jackY
Power
AC adapter input voltage100 - 240
Input current2.5
AC adapter output voltage54
Output current3.3
Total Power over Ethernet (PoE) budget160
Certificates
Compliance certificatesCE,Federal Communications Commission (FCC),UKCA
Sustainability
Sustainability complianceY
Operational conditions
Operating temperature (T-T)0 - 50
Operating relative humidity (H-H)5 - 95
Storage temperature (T-T)-10 - 70
Storage relative humidity (H-H)5 - 95
Weight & dimensions
Width70
Depth94
Height39
Weight278
Packaging content
Number of products included1
AC adapter includedY
Quick installation guideY
Packaging data
Package width170
Package depth300
Package height90
Package weight1700
Logistics data
Master (outer) case width475
Master (outer) case length370
Master (outer) case height325
Products per master (outer) case10
