ASUS ExpertCenter PN64-S7018MDE1 Intel® Core™ i7 i7-13700H 16 GB DDR5-SDRAM 512 GB SSD Mini PC Black
ASUS ExpertCenter PN64-S7018MDE1, Intel® Core™ i7, i7-13700H, 16 GB, DDR5-SDRAM, 512 GB, SSD
Availability:: Arriving soon
New Processor Architecture DesignASUS ExpertCenter PN64 is powered by the new 12th Gen Intel® Core™ CPU featuring a new hybrid processor design. It includes performance-cores (P-cores) dedicated to processing heavy loads and prioritized tasks, as well as efficient-cores (E-cores) catering to background tasks such as web browsing and PowerPoint presentations. This new core design enables PN64 to process multiple tasks simultaneously in the most efficient way possible.Superior Computing PerformanceASUS ExpertCenter PN64 delivers superior performance, allowing users to get more done effortlessly, with greater efficiency. Compared to the previous generation PN63-S1 model, PN64 offers a 28% boost on overall system performance, making it perfect for multitasking**.Faster and better DDR5 RAMASUS ExpertCenter PN64 is powered by the new 12th Gen Intel® Core™ CPU supporting the next gen memory - DDR5. With DDR5 4800MHz memory that is 1.5X faster and 8% more energy efficient than DDR4 3200MHz memory, PN64 provides excellent performance for daily computing tasks.Ultrafast PCIe® 4.0 SSDASUS ExpertCenter PN64 supports one PCIe® Gen 4 X4 SSD to deliver low-latency data transfers at speeds of up to 8 GB/s, that’s twice the data transfer speeds of PCIe 3.0.Superfast 2.5 Gbps EthernetASUS ExpertCenter PN64 features next-generation 2.5GBASE-T technology for superfast 2.5 Gbps networking speeds, enabling it to make light work of the most data-intensive tasks.Modern, Space-saving DesignCompact and stylish, ASUS ExpertCenter PN64 has a contemporary look that suits any home or officeUltra-realistic 8K VisualsASUS ExpertCenter PN64 delivers breathtaking 8K visuals at 30 frames per second via the configurable standard DisplayPort or DisplayPort over USB-C. Experience a level of detail that’s 4X greater than 4K, or 16X that of traditional FHD output.USB Power Delivery InputASUS ExpertCenter PN64 can draw power from any USB Power Delivery-enabled display or device, eliminating the need for a separate power adapter to create a neater, uncluttered workspace.4K Resolution & Quad Display SupportASUS ExpertCenter PN64 can support up to four 4K displays via two HDMI® ports, two DisplayPort™ over USB-C® or other user-configurable ports, without any limitation on the combination used.Configurable PortASUS ExpertCenter PN64 is well-equipped for a wide range of functions and can be used for digital signage, POS systems or intelligent vending machines. The configurable port can be specified with either HDMI, VGA, DisplayPort, or COM ports, as well as 2.5 Gb LAN, for monitors or legacy devices such as barcode scanners and receipt printers.Padlock Ring for SecurityThe chassis of ASUS ExpertCenter PN64 can be secured with a standard padlock to prevent access to internal components.VESA Mount-lockable DesignASUS ExpertCenter PN64 can even be locked onto a VESA mount for additional security.Enhanced Software - MyASUSAI Noise CancelationTwo-Way AI Noise CancelationFilters unwanted noise from the microphone and incoming audio for crystal-clear voice communication.System DiagnosisHardware diagnosticScenario check-upProvides brief descriptions to enable users to identify different situations encountered and select the ideal diagnostic checkup required.Smart Fan ControlPerformance & Quiet modesGives users the flexibility to use maximum fan speed during heavy loads or switch to a lower speed for silent operation.Other FunctionsWiFi SmartConnectOptimizes the wireless connectionTaskFirstAllocate networking bandwidth to specific tasks.Link to MyASUSAllows users to connect the computer to a mobile device.
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Core i7 |
| Processor generation | Intel Core i7-13xxx |
| Processor model | i7-13700H |
| Processor cores | 14 |
| Processor boost frequency | 5 |
| Processor cache | 24 |
| Configurable TDP-down | 35 |
| Memory | |
| Internal memory | 16 |
| Internal memory type | DDR5-SDRAM |
| Memory slots | 2x SO-DIMM |
| Memory clock speed | 4800 |
| Storage | |
| Total storage capacity | 512 |
| Storage media | SSD |
| Optical drive type | N |
| Total SSDs capacity | 512 |
| Number of SSDs installed | 1 |
| SSD capacity | 512 |
| SSD interface | PCI Express 4.0 |
| NVMe | Y |
| SSD form factor | M.2 |
| Graphics | |
| Discrete graphics card | N |
| On-board graphics card | Y |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card model | Intel Iris Xe Graphics |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 10,100,1000,2500 |
| LAN controller | Intel I225-V |
| Wi-Fi | Y |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Antenna type | 2x2 |
| Bluetooth | Y |
| Bluetooth version | 5.2 |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Microphone in | Y |
| Headphone outputs | 1 |
| Line-out | Y |
| DC-in jack | Y |
| Design | |
| Chassis type | Mini PC |
| Colour name | ECO Black |
| Volume | 0.6 |
| Placement supported | Horizontal/Vertical |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Performance | |
| Audio chip | Realtek ALC3251-CG |
| Audio system | High Definition Audio |
| Built-in speaker(s) | N |
| Product type | Mini PC (<= 3L) |
| Software | |
| Operating system installed | N |
| Processor special features | |
| CPU configuration (max) | 1 |
| Certificates | |
| Certification | BSMI/CB/CE/FCC/UL/CCC/Energy Star/C-Tick/WiFi/RF/VCCI |
| Weight & dimensions | |
| Width | 120 |
| Depth | 130 |
| Height | 58 |
| Weight | 700 |
| Package width | 286 |
| Package depth | 175 |
| Package height | 68 |
| Package weight | 1840 |
| Display | |
| Display included | N |
