ICY BOX IB-M2HSF-705 Solid-state drive Heatsink/Radiator 3 cm Silver 1 pc(s)
ICY BOX IB-M2HSF-705, Heatsink/Radiator, 3 cm, 8500 RPM, 4.87 m³/h, Silver
Availability:: Arriving soon
Powerful cooling performanceThe swivelling ICY BOX® heatpipe cooler reduces the temperature of your M.2 SSD (form factor 2280) by up to 40%. Due to the excellent interaction of cooling fins and fan, a cooling capacity of 23 W TDP is achieved. Depending on SSD manufacturer, model and version, as well as load of the SSD.Perfectly positionedThe possibility to swivel the ICY BOX® heatpipe cooler allows the airflow in the enclosure to be optimally directed. It can also be positioned flexibly, which creates additional space for graphics cards or PCIe expansion cards. This allows you to fit even more performance into small enclosures.Silent fanThe 30 mm PVM fan has an output of 8500 rpm and a volume flow of approx. 4.9 m³/h. You can further optimise the fan settings for yourself via the BIOS. This makes it possible to achieve cooling that is perfectly matched to the system. The fan is pleasantly quiet even under high demands.
| Performance | |
|---|---|
| Suitable location | Solid-state drive |
| Type | Heatsink/Radiator |
| Fan diameter | 30 |
| Number of speeds | 1 |
| Rotational speed (max) | 8500 |
| Maximum airflow | 2.87 |
| Airflow | 4.87 |
| Quantity per pack | 1 |
| Thermal conductivity | 1.5 |
| Operating temperature (T-T) | -20 - 180 |
| Design | |
| Product colour | Silver |
| Material | Aluminium,Copper |
| Number of fans | 1 |
| Number of fins | 22 |
| Number of heat pipes | 1 |
| Fan connector | 4-pin |
| Power | |
| Voltage | 12 |
| Rated current | 0.09 |
| Thermal Design Power (TDP) | 23 |
| Weight & dimensions | |
| Width | 30 |
| Depth | 75 |
| Height | 50 |
| Weight | 86 |
| Fan dimensions (W x D x H) | 30 x 30 x 7 |
| Heat pipes diameter | 6 |
| Fins thickness | 0.5 |
| Cable length | 0.5 |
| Package width | 100 |
| Package depth | 200 |
| Package height | 40 |
| Package weight | 190 |
| Packaging content | |
| Screws included | Y |
| Thermal pad included | Y |
| Other features | |
| Country of origin | China |
| Logistics data | |
| Harmonized System (HS) code | 84145915 |
| Master (outer) case width | 225 |
| Master (outer) case length | 440 |
| Master (outer) case height | 425 |
| Master (outer) case gross weight | 7600 |
| Products per master (outer) case | 40 |
