Axagon EE35-XA3 storage drive enclosure HDD enclosure Black 3.5"
Axagon EE35-XA3 storage drive enclosure HDD enclosure Black 3.5"
€17,35

Axagon EE35-XA3, HDD enclosure, 3.5", Serial ATA, Serial ATA II, Serial ATA III, 5 Gbit/s, USB connectivity, Black

Availability:: Arriving soon
EAN:8595247902863Categories:Storage

The compact aluminium AXAGON EE35-XA3 ALINE external box with a high-speed USB 3.2 Gen 1 (USB 3.0) interface intended for 3.5" SATA disks.The UASP support allows you to enjoy the most possible speed of modern disks.Reading of S.M.A.R.T. information monitoring the condition of the external disk. Supports spinning down of connected disks as well as the box.Durable cast aluminum case for perfect mechanical protection of the disk and excellent heat dissipation.The decently shaped case with a brushed surface that provides elegant look and prevents unwanted fingerprints.Easy installation of the hard disk as well as automatic installation can be handled even by a layman and easily create an external disk.Input:• USB 3.2 Gen 1 (USB 3.1 Gen 1 / USB 3.0) SuperSpeed USB transmission rates up to 5 Gbit/s.• Connection via micro USB type B female conector.Device support:• SATA II - 3 Gb/s (300 MB/s) interface, • Supports 3,5“ HDD.Features:• Compatible with USB 3.2 Gen 1 / USB 3.1 Gen 1 / USB 3.0 and backward compatible with USB 2.0.• Supports transmission rates 5000 / 480 Mbit/s (SuperSpeed / HighSpeed).• Supports 3.5" SATA III / II / I disks of all capacities without limitation.• Compliant with Serial ATA 2.0 specification (SATA/300), transmission rates of up to 3 Gb/s (300 MB/s).• Compliant with Serial ATA 1.0 specification (SATA/150), transmission rates of up to 1.5 Gb/s (150 MB/s).• The total bandwidth / transmission rate of the box is determined by the SATA/300 interface used (theor. 3 Gbit/s).• Supports UASP (USB Attached SCSI Protocol).• SSD/HDD boot support in external box.• Possibility to connect your device while running thanks to the Hot Plug support.• Full Plug and Play support.• HDD Auto Spindown support - possibility to set the interval for disk spindown when idle.• HDD Turn Off - turns off the disk after removing the device or spinning down the PC.• Connection via durable large USB 3.2 Gen 1 Type B female connector.• An USB-B / USB-A cable 80 cm long is included.• A blue, decent LED indicates the connection to the computer's USB port (permanent light) and the data transmission (blinking).• The durable box body is a cast aluminum alloy, the box faces are plastic.• Simple disk installation - the guides are mounted on the disk, the disk is plugged directly into the SATA connector of the motherboard, and inserted into the box body; the front panel is fastened with two screws using a screwdriver that is included.• Compact adapter dimensions 180 x 120 x 32 mm.• External box weight 244 g (without cables and disk).Power supply:• Power supply via a compact external AC/DC adapter 12 V - 2.5 A (24 W) with a 150 cm long supply cable.• Power switch on the rear panel of the box.• AC adapter dimensions 74 x 36 x 91 mm (incl. fork).• AC adapter weight 128 g (incl. supply cable). Supported OSs:• MS Windows XP / Vista / 7 / 8 / 8.1 / 10 and later, Windows Server 2003 / 2008 / 2012 / 2016 and later (supported are all 32- and 64-bit Windows OS versions), Mac OS X 10.x and higher, Linux with kernel 2.6.x and above.• Note: Drivers are included with supported operating systems and are installed completely automatically. No other drivers need to be installed and are not even available.Package contains:• USB 3.2 Gen 1 external box for 3.5" SATA,• USB-B - USB-A cable 80 cm long,• power adapter 100-240V / 12V-2A,• mounting strips, screws and the screwdriver,• a stand that allows the box to be operated in upright position,• printed installation guide in CZ/DE/DK/ENG/ESP/FIN/FR/GR/HR/HU/IT/NL/PL/PT/RO/RU/SK/SWE/BG/CN/TR/ARA,• packed in a cardboard box.

Storage
Number of storage drives supported1
Storage drive size3.5 "
Supported storage drive interfacesSerial ATA,Serial ATA II,Serial ATA III
Ports & interfaces
USB connectivityY
USB version3.2 Gen 1 (3.1 Gen 1)
USB connector typeUSB Type-B
USB connector genderFemale connector
USB ports quantity1
DC-in jackY
Design
Product typeHDD enclosure
Product colourBlack
MaterialAluminium,Plastic
LED indicatorsY
On/off switchY
CertificationCE, FCC
Performance
Data transfer rate5 Gbit/s
UASP supportY
S.M.A.R.T. supportY
Plug and PlayY
Power
Power source typeAC
External power adapterY
AC adapter input voltage100 - 240 V
AC adapter output voltage12 V
AC adapter output current2.5 A
System requirements
Mobile operating systems supportedY
Windows operating systems supportedWindows 10,Windows 7,Windows 8,Windows 8.1,Windows Vista,Windows XP
Linux operating systems supportedY
Mac operating systems supportedY
Weight & dimensions
Width180 mm
Depth120 mm
Height32 mm
Weight244 g
Cable length0.8 m
Package width202 mm
Package depth163 mm
Package height80 mm
Package weight548 g
Packaging content
Package typeBox
AC adapter includedY
Cables includedUSB Type-A to USB Type-B
Stand includedY
Screws includedY
Screwdriver includedY
ManualY
Technical details
Compliance certificatesRoHS
