Shuttle XPC nano NS02EV2 Rockchip RK3368 2 GB DDR3L-SDRAM 16 GB eMMC Android 8.1 Nettop Mini PC Black
Shuttle XPC nano NS02EV2, Rockchip, RK3368, 2 GB, DDR3L-SDRAM, 16 GB, Android 8.1
Availability:: Arriving soon
0.5-litre fanless PC with Android supports HDMI 2.0 and PoE The Shuttle XPC nano NS02EV2 is one of the most affordable models Shuttle's product family of Mini PCs has on offer. It not only convinces by its stunning looks and reliable long-term performance alone, it also comes with an integrated Octa-Core ARM processor and pre-installed Android operating system. Featuring HDMI 2.0, 4x USB 2.0, Gigabit-LAN, WLAN-ac and a built-in card reader, they easily connect to diverse peripheral devices for different kinds of application. The NS02EV2 version includes Power-over-Ethernet (PoE). This product is particularly intended for digital signage and Thin Client applications.
| Processor | |
|---|---|
| Processor manufacturer | Rockchip |
| Processor family | Rockchip |
| Processor model | RK3368 |
| Processor cores | 8 |
| Processor boost frequency | 1.5 GHz |
| Memory | |
| Internal memory | 2 GB |
| Maximum internal memory | 2 GB |
| Internal memory type | DDR3L-SDRAM |
| Storage | |
| Total storage capacity | 16 GB |
| Storage media | eMMC |
| Optical drive type | N |
| Card reader integrated | Y |
| Compatible memory cards | SD,SDHC,SDXC |
| Graphics | |
| Discrete graphics card | N |
| On-board graphics card | Y |
| Discrete graphics card model | Not available |
| On-board graphics card model | PowerVR SGX6110 |
| Graphics card Open GL support | Y |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| LAN controller | Realtek RTL8211F-CG |
| Wi-Fi | Y |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
| Bluetooth | Y |
| Bluetooth version | 5.0 |
| Wake-on-LAN ready | Y |
| Ports & interfaces | |
| USB 2.0 ports quantity | 4 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Line-out | Y |
| DC-in jack | Y |
| Design | |
| Chassis type | Nettop |
| Volume | 0.577 L |
| VESA mounting | Y |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Housing material | Plastic |
| Performance | |
| Audio chip | Realtek ALC5640-VB |
| Password protection | Y |
| Product type | Mini PC (<= 3L) |
| Software | |
| Operating system installed | Android 8.1 |
| Power | |
| Power supply | 24 W |
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50 - 60 Hz |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | CE, FCC, BSMI, RCM, VCCI |
| Sustainability | |
| Sustainability certificates | ErP |
| Weight & dimensions | |
| Width | 141 mm |
| Depth | 141 mm |
| Height | 29 mm |
| Weight | 270 g |
| Package weight | 650 g |
| Packaging content | |
| VESA mount included | Y |
| Logistics data | |
| Harmonized System (HS) code | 84715000 |
| Display | |
| Display included | N |
