ASUS PRIME B760M-K Intel B760 LGA 1700 micro ATX
(0 review)Add your review
€87,79

ASUS PRIME B760M-K, Intel, LGA 1700, Intel® Celeron®, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™..., LGA 1700, DDR5-SDRAM, 96 GB

Availability:: Arriving soon
EAN:4711387198506Categories:Hardware Components

B760M-KASUS Prime series motherboards are expertly engineered to unleash the full potential of 13th Gen Intel® Core™ Processors. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, PRIME B760M-K provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features.FLEXIBILITYComprehensive controls form the foundation of the ASUS PRIME series. The PRIME B760 motherboard packs flexible tools to tune every aspect of your system, enabling performance tweaks to perfectly match the way you work to maximize productivity.Intelligent ControlASUS Intelligent Control makes your PC smart. Along with taking care of complex tuning and dynamically optimizing essential aspects of your system, it offers intelligently simplified options for newcomers to PC DIY, as well as more comprehensive features for seasoned veterans.All-Around Energy EfficiencyThe Power Saving function contains several settings can easily optimize power consumption and maximize energy savings. You can enable a CPU power limit, darken Aura lighting, and set the fan profile to a power saving mode. You can also toggle the Power Saver plan that is built into Microsoft Windows.

Processor
Processor manufacturerIntel
Processor socketLGA 1700
Compatible processor seriesIntel Celeron,Intel Pentium Gold,Intel Core i3,Intel Core i5,Intel Core i7,Intel Core i9
Maximum number of SMP processors1
Supported processor socketsLGA 1700
Memory
Supported memory typesDDR5-SDRAM
Number of memory slots2
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilitynon-ECC
Supported memory clock speeds8000,7800,7600,7400,7200,7000,6800,6600,6400,6200,6000,5800,5600,5400,5200,5000,4800 MHz
Supported memory clock speed (max)8000 MHz
Maximum internal memory96 GB
Unbuffered memoryY
Storage controllers
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2,SATA III
Number of HDDs supported4
Number of storage drives supported6
RAID supportY
RAID levels0,1,5,10
Graphics
Parallel processing technology supportNot supported
Internal I/O
USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Number of SATA III connectors4
S/PDIF out connectorY
Front panel audio connectorY
ATX Power connector (24-pin)Y
CPU fan connectorY
Number of chassis fan connectors1
EPS power connector (8-pin)Y
Number of COM connectors1
TPM connectorY
12V power connectorY
RGB LED pin headerY
Rear panel I/O ports
USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Ethernet LAN (RJ-45) ports1
PS/2 ports quantity1
VGA (D-Sub) ports quantity1
HDMI ports quantity1
S/PDIF out portY
Network
Ethernet LANY
Ethernet interface type2.5 Gigabit Ethernet
Wi-FiN
Features
Motherboard chipsetIntel B760
Audio output channels7.1 channels
Component forPC
Motherboard form factorMicro ATX
Motherboard chipset familyIntel
Windows operating systems supportedWindows 10 x64,Windows 11
Expansion slots
PCI Express x1 (Gen 4.x) slots2
PCI Express x16 (Gen 4.x) slots1
Number of M.2 (M) slots2
BIOS
BIOS typeUEFI AMI
BIOS memory size128 Mbit
Packaging data
Package width270 mm
Package depth263 mm
Package height51.5 mm
Package weight1015 g
Weight & dimensions
Width244 mm
Depth211 mm
Packaging content
Cables includedSATA
0.00
0 Review
0 review for "ASUS PRIME B760M-K Intel B760 LGA 1700 micro ATX"
