Kingston Technology 480G DC600M (Mixed-Use) 2.5” Enterprise SATA SSD
Kingston Technology 480G DC600M (Mixed-Use) 2.5” Enterprise SATA SSD, 480 GB, 2.5", 560 MB/s, 6 Gbit/s
Availability:: Arriving soon
Kingston’s DC600M and DC600ME SSDs are fourth-generation data center SATA 3.0, 6Gbps SSDs utilising 3D TLC NAND intended for “mixed use” server workloads. Both are well suited for a wide variety of server applications and include on-board power loss protection via hold-up capacitors. DC600M and DC600ME are designed to protect data against unexpected power failure and to ensure the drive will successfully reinitialise on the next power-up of the system. Designed to deliver low latency and IO consistency for system integrators, hyperscale data centers and cloud service providers. DC600ME features AES 256-bit encryption and supports TCG OPAL 2.0 security standards. Capacities available from 480GB–7.68TB* to meet your data storage requirements.Designed for data center environments Optimised to meet the high demands of server RAID applications with low latency and IO consistency as the key design criteria.Hardware-based PLPPower loss capacitors to protect user data against unexpected power loss and enhance performance.Delivers excellent quality of service (QoS)*Optimised performance predictability to meetservice-level agreements (SLAs).AES 256-bit Encryption with DC600ME Protect sensitive data with support for AES 256-bit hardware-based encryption and TCG Opal 2.0 security standards with DC600ME. Capacities up to 7.68TB Upgrade and manage storage with capacities up to 7.68TB.*
| Features | |
|---|---|
| SSD capacity | 480 GB |
| SSD form factor | 2.5" |
| Interface | Serial ATA III |
| Memory type | 3D TLC NAND |
| Component for | Server/Workstation |
| Hardware encryption | N |
| Target workload | Mixed Use (MU) |
| Data transfer rate | 6 Gbit/s |
| Read speed | 560 MB/s |
| Write speed | 470 MB/s |
| Random read (4KB) | 94000 IOPS |
| Random write (4KB) | 41000 IOPS |
| Read latency | 200 µs |
| Write latency | 30 µs |
| Hot-Plug support | Y |
| H/W PLP function | Y |
| Mean time between failures (MTBF) | 2000000 h |
| TBW rating | 876 |
| Use conditions | Server/Enterprise |
| Power | |
| Power consumption (read) | 1.6 W |
| Power consumption (write) | 3.6 W |
| Power consumption (average) | 1.45 W |
| Power consumption (idle) | 1.3 W |
| Weight & dimensions | |
| Width | 69.85 mm |
| Depth | 100.1 mm |
| Height | 7 mm |
| Weight | 66 g |
| Packaging data | |
| Package width | 129.54 mm |
| Package depth | 9.14 mm |
| Package height | 184.15 mm |
| Package weight | 88.19 g |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating vibration | 2.17 G |
| Non-operating vibration | 20 G |
| Logistics data | |
| Country of origin | China,Taiwan |
| Master (outer) case width | 135.89 mm |
| Master (outer) case length | 203.2 mm |
| Master (outer) case height | 69.85 mm |
| Master (outer) case gross weight | 959.95 g |
| Products per master (outer) case | 10 pc(s) |
