StarTech.com U.3 to PCIe Adapter Card, PCIe 4.0 x4 Adapter For 2.5" U.3 NVMe SSDs, SFF-TA-1001 PCI Express Add-in Card for Desktops/Servers, TAA Compliant - OS Independent
(0 review)Add your review
€50,33

StarTech.com U.3 to PCIe Adapter Card, PCIe 4.0 x4 Adapter For 2.5" U.3 NVMe SSDs, SFF-TA-1001 PCI Express Add-in Card for Desktops/Servers, TAA Compliant - OS Independent, PCIe, U.3, Red, Activity, Power, 21693912 h, 0 - 60 °C

Availability: In Stock
EAN:0065030899000Categories:NetworkingTags:

Mount a 2.5" U.3 NVMe SSD into a desktop computer or server, utilizing a PCIe x4 expansion slotAdd a 2.5 inch U.3 NVMe SSD into a PCIe 4.0 x4/x8/x16 slot in a desktop or server using the included screws, enabling ultra-fast data access.Add U.3 Capabilities to a Desktop or ServerInstall an SFF-TA-1001 SSD into a desktop or server using an available PCI Express 4.0 slot. The pre-installed full-profile bracket and included drive mounting screws enable the connection of a U.3 NVMe drive to a PCIe slot, avoiding the need for a drive backplane or additional cables. This adapter is not compatible with U.2 drives.Universal CompatibilityThe Adapter Card is backward compatible with motherboards that feature x4, x8, and/or x16 PCIe 3.0 slots. The U.3 Adapter requires no additional drivers or software and works with all workstation and server operating systems, such as Windows, Windows Server, and Linux.Optimal Airflow and Reliable PerformanceThe vented full-profile bracket and a large cutout in the PCB allow for better airflow and heat dissipation, which helps maintain optimal and reliable performance while avoiding thermal throttling.The StarTech.com Advantage

Ports & interfaces
Host interfacePCIe
Output interfaceU.3
Design
InternalY
Product colourRed
LED indicatorsActivity,Power
Mean time between failures (MTBF)21693912 h
Hot-swapN
Features
Plug and PlayY
Operational conditions
Operating temperature (T-T)0 - 60 °C
Storage temperature (T-T)-40 - 80 °C
Operating relative humidity (H-H)20 - 80 %
System requirements
Supported storage drive heights5,7,9.5,12.5,15 mm
Weight & dimensions
Width90 mm
Depth154 mm
Height1.5 mm
Weight62 g
Packaging data
Screws includedY
Quick installation guideY
Package width215 mm
Package depth155 mm
Package height30 mm
Package weight130 g
Logistics data
Products per master (outer) case60 pc(s)
Master (outer) case width460 mm
Master (outer) case length340 mm
Master (outer) case height490 mm
