Intellinet Transceiver Module Optical, Gigabit Fiber SFP Mini-GBIC, 1000Base-Lx (LC) Single-Mode Port, 20km, Wavelength 1310nm, Ethernet, Fibre, MSA Compliant, Equivalent to Cisco GLC-LH-SM, Three Year Warranty
Intellinet Transceiver Module Optical, Gigabit Fiber SFP Mini-GBIC, 1000Base-Lx (LC) Single-Mode Port, 20km, Wavelength 1310nm, Ethernet, Fibre, MSA Compliant, Equivalent to Cisco GLC-LH-SM, Three Year Warranty, Fiber optic, 1000 Mbit/s, mini-GBIC, LC, 9/125 µm, LX
Availability:: Arriving soon
The new Intellinet Network Solutions Small Form Factor Pluggable (SFP) Transceiver provides the best combination of performance and affordability. This mini-GBIC (Gigabit Interface Converter) module provides a metal housing to reduce electromagnetic interference and increases durability. _x000D_ _x000D_Small Size for High-Density Fibre Connections _x000D_The transceiver is available as a mini-GBIC form factor, making it ideal for environments that require many fibre connections by taking up less space in your cabinet and/or computer room. _x000D_ _x000D_Multi-Vendor Compatible _x000D_Compatibility in your network is everything, and the Intellinet SFP Transceiver Module delivers. Use it with any Intellinet SFP equipped network switch or any other MSA-compliant, SFP-enabled switch. And since the Intellinet SFP transceiver module is set to broadcast the vendor on GLC-LH-SM, compatibility to your Cisco gear is provided. _x000D_ _x000D_Hot-Pluggable _x000D_No need to power down your LAN switch in order to install or remove the transceiver. This makes it very convenient and easy for you to make adjustments to your network that allow your business to keep pace with the changing demands of the market.
| Performance | |
|---|---|
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 1000 Mbit/s |
| Interface type | mini-GBIC |
| Single-mode fiber (SMF) supported | Y |
| Multi-mode fiber (MMF) supported | N |
| Fiber optic connector | LC |
| Fiber cable diameters supported (core/cladding) | 9/125 µm |
| SFP transceiver standard | LX |
| Maximum transfer distance | 20000 m |
| Wavelength | 1310 nm |
| Tx power (min) | -8 dBmW |
| Tx power (max) | -3 dBmW |
| Link budget | 8 dB |
| Ethernet interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.3z |
| Duplex system | Full,Half |
| Features | |
| Product colour | Aluminium |
| Hot-Plug support | Y |
| Power | |
| Input voltage | 3.3 V |
| Power consumption (typical) | 1 W |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | FCC Class A, CE, RoHS, IEC-60825 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 85 % |
| Weight & dimensions | |
| Width | 13 mm |
| Depth | 55 mm |
| Height | 12 mm |
| Weight | 62 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Harmonized System (HS) code | 85369010 |
