Chieftec Smart 300W power supply unit 20+4 pin ATX TFX Grey
Chieftec Smart 300W, 300 W, 115 - 230 V, 47 - 63 Hz, 6.3 A, Active, 95 W
Availability: In Stock
The latest generation of TFX power supplies comes with a new model: GPF-300P (12V version 2.3). Equipped with both a state-of-the-art interior and 80PLUS® Bronze efficiency, this power supply is ideal for home entertainment systems or small size systems. Compatible with both Intel/AMD processors, featuring with active PFC and a smooth running, temperature-controlled fan, the CHIEFTEC GPF-300P provides reliable performance for enthusiast seeking for efficiency.
| Power | |
|---|---|
| Total power | 300 W |
| AC input voltage | 115 - 230 V |
| AC input frequency | 47 - 63 Hz |
| Input current | 6.3 A |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 95 W |
| Combined power (+5V) | 95 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 10 W |
| Max output current (+3.3V) | 16 A |
| Max output current (+12V1) | 14 A |
| Max output current (+12V2) | 15 A |
| Max output current (+5V) | 15 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2 A |
| Power protection features | Over voltage,Overheating,Overload,Short circuit,Under voltage |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 300 mm |
| Number of SATA power connectors | 4 |
| SATA power cable length | 150,350 mm |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Peripheral (Molex) power cable length | 150,350 mm |
| EPS power connector (4+4 pin) | Y |
| CPU power cable length | 350 mm |
| Floppy drive power connector | 1 |
| Floppy disk drive cable length | 150 mm |
| Cabling type | Non-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Bronze |
| Purpose | PC/server |
| Power supply unit (PSU) form factor | TFX |
| ATX version | 2.3 |
| Design | |
| Product colour | Grey |
| Cooling type | Active |
| Fan diameter | 80 mm |
| Number of fans | 1 fan(s) |
| Certificates | |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Width | 85 mm |
| Depth | 175 mm |
| Height | 65 mm |
| Weight | 1070 g |
| Packaging data | |
| Package weight | 1130 g |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
