TP-Link Omada AX1800 Ceiling Mount WiFi 6 Access Point
TP-Link Omada AX1800 Ceiling Mount WiFi 6 Access Point, 2.4 GHz, 5 GHz, 1201 Mbit/s, SNMP, SNMPv2, SNMPv3, SSH, WEP, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3, WPA3-PSK, 10,100,1000 Mbit/s
Availability: In Stock
High-Density Connectivity with 4× Increased CapacityOFDMA* and Uplink & Downlink MU-MIMO increase network capacity by up to 4× versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously. Leverage multi-user capabilities and upgrade your business like never before.Advanced Wi-Fi Speed with 4 Spatial StreamsThe Omada Wi-Fi 6 Access Point features the latest 802.11ax technologies like 1024 QAM and Long OFDM Symbol, which allows the EAP to boost overall speeds up to 1775 Mbps (1201 Mbps on a 5 GHz band and 574 Mbps on a 2.4 GHz band). With 8 spatial streams, multi-user throughput is incredibly increased to drive more applications.Omada SDN—Smarter Cloud Solution for Business NetworkingOmada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.Seamless Roaming802.11k/v roaming switches clients automatically to the AP with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.Secure Guest Network with Facebook Wi-Fi and SMS LoginGuest Network provides elevated secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and power up your business.
| Features | |
|---|---|
| 2.4 GHz | Y |
| 5 GHz | Y |
| 6 GHz | N |
| Maximum data transfer rate | 1201 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
| Maximum data transfer rate (5 GHz) | 1201 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Frequency band | 2.4 - 5 GHz |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3at |
| Cabling technology | 10/100/1000Base-T(X) |
| Number of users | 1020 user(s) |
| Automatic channel selection | Y |
| Automatic channel scanning | Y |
| MIMO | Y |
| MIMO type | Multi User MIMO |
| Spread spectrum method | OFDMA |
| Fit AP mode features | Mesh networking |
| VLAN support | Y |
| Rate limiting | Y |
| Flow control support | Y |
| Band steering | Y |
| Airtime Fairness (ATF) | Y |
| Quality of Service (QoS) support | Y |
| BeamForming | Y |
| Transmitting power (CE) | 20/23 dBm |
| Transmitting power (FCC) | 23 dBm |
| Security | |
| Security algorithms | SNMP,SNMPv2,SNMPv3,SSH,WEP,WPA-Enterprise,WPA-PSK,WPA2-Enterprise,WPA2-PSK,WPA3,WPA3-PSK |
| MAC address filtering | Y |
| Remote Authentication Dial-In User Service (RADIUS) | Y |
| Access Control List (ACL) | Y |
| Management features | |
| Web-based management | Y |
| Syslog | Y |
| Firmware upgradeable | Y |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Y |
| Power | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) type supported | Active PoE,Passive PoE |
| DC voltage range | 12 V |
| Design | |
| Placement | Ceiling,Wall |
| Product colour | White |
| Reset button | Y |
| LED indicators | Y |
| Antenna | |
| Antenna type | Internal |
| Antenna direction type | Omni-directional |
| Certificates | |
| Certification | CE, FCC, RoHS |
| Weight & dimensions | |
| Width | 160 mm |
| Depth | 160 mm |
| Height | 33 mm |
| Packaging data | |
| Package type | Box |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Mounting kit | Y |
| Quick start guide | Y |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
