LevelOne AC1200 Dual Band Outdoor PoE Wireless Access Point, Controller Managed

€239,87

LevelOne AC1200 Dual Band Outdoor PoE Wireless Access Point, Controller Managed, 2.4 GHz, 5 GHz, 1200 Mbit/s, 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, 10,100,1000 Mbit/s

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:4015867200384Categories:Networking

The LevelOne WAB-8011 is a managed, outdoor dual-band 802.11ac/n wireless access point, capable of a combined speed of up to 1200 Mbps. The device runs on 2.4 and 5 GHz frequencies, and can be used as part of a managed network when controlled by the LevelOne WAC-2000/WAC-2003 Wireless LAN Controller. LevelOne WAB-8011 also offers PoE, removing the need for an external power supply, which makes it easy to install. Advanced weatherproof design, rated to IP65 means the WAP is designed for outdoor deployments, and can withstand rain, humidity, dust, snow and extremely hot conditions. A fast, versatile and secure access point for a wide variety of outdoor network requirements. The LevelOne WAB-8011 is a managed, outdoor dual-band 802.11ac/n wireless access point, capable of a combined speed of up to 1200 Mbps. The device runs on 2.4 and 5 GHz frequencies, and can be used as part of a managed network when controlled by the LevelOne WAC-2000/WAC-2003 Wireless LAN Controller. LevelOne WAB-8011 also offers PoE, removing the need for an external power supply, which makes it easy to install. Advanced weatherproof design, rated to IP65 means the WAP is designed for outdoor deployments, and can withstand rain, humidity, dust, snow and extremely hot conditions. A fast, versatile and secure access point for a wide variety of outdoor network requirements.

Features
2.4 GHz	Y
5 GHz	Y
Maximum data transfer rate	1200 Mbit/s
Wi-Fi data rate (max)	433 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Frequency band	2.4 - 2.483, 5.15 - 5.35, 5.46 - 5.72, 5.725 - 5.82 GHz
Networking standards	IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11e,IEEE 802.11g,IEEE 802.11i,IEEE 802.11n,IEEE 802.3,IEEE 802.3ab,IEEE 802.3at,IEEE 802.3u
Number of users	100 user(s)
Channels quantity	165 channels
Modulation	16-QAM,64-QAM,BPSK,CCK,DBPSK,DQPSK,DSSS,OFDM
Wi-Fi Multimedia (WMM)/(WME)	Y
Operating modes	Access Point (AP),Gateway,Repeater,WISP
Quality of Service (QoS) support	Y
Security
Security algorithms	64-bit WEP,128-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK
Service Set Identifier (SSID) features	SSID broadcast on/off
Number of SSID supported	4
Management features
Web-based management	Y
Firmware upgradeable	Y
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
WAN connection	Ethernet (RJ-45)
Power
Power over Ethernet (PoE)	Y
Power consumption (typical)	30 W
Design
Product colour	Grey
International Protection (IP) code	IP65
Reset button	Y
Internal	N
Antenna
Antenna connector type	N-type
Number of connectors	4
Certificates
Certification	CE, FCC
Weight & dimensions
Width	230 mm
Depth	380 mm
Height	85 mm
Weight	4000 g
Packaging data
CD manual	Y
CD quick installation guide	Y
Package width	285 mm
Package depth	455 mm
Package height	125 mm
Package weight	4400 g
Package type	Box
Packaging content
Mounting kit	Y
Quick start guide	Y
Operational conditions
Operating relative humidity (H-H)	10 - 90 %
Operating temperature (T-T)	-40 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Logistics data
Harmonized System (HS) code	85176990
Country of origin	China
Master (outer) case width	475 mm
Master (outer) case length	650 mm
Master (outer) case height	305 mm
Master (outer) case gross weight	23500 g
Products per master (outer) case	5 pc(s)
