StarTech.com 5-port industrial Ethernet switch - DIN rail mountable
(0 review)Add your review
€98,51

StarTech.com 5-port industrial Ethernet switch - DIN rail mountable, Unmanaged, Fast Ethernet (10/100), Full duplex, Rack mounting

Availability: In Stock
EAN:0065030859745Categories:NetworkingTags:

Expand your network connectivity with this rugged unmanaged 10/100Mbps switchThis compact 5-port industrial Ethernet switch is engineered to deliver fast, reliable network connectivity and durability in the most demanding industrial environments. It provides top performance in a wider range of operating temperatures than conventional network switches, making it ideal for factories and warehouses.Conquer the tough demands of industrial environmentsDesigned with a rugged IP30-rated housing, the network switch delivers maximum performance even in harsh industrial conditions. Its wide-range terminal block input gives you the flexibility to power the switch as required, based on your own power input source, while its wide operating temperature range keeps your network running smoothly.Get up and running in no timeThis industrial Ethernet switch is easy to install, with an attached metal bracket for DIN rail mounting on equipment racks and cabinets.Now you can eliminate the hassle of troubleshooting mismatched speed and duplex settings. This switch gives you full/half-duplex auto-negotiation and auto MDI/MDIX operation, enabling you to connect your network devices quickly and easily with little to no configuration required.Reduce your energy costs with Energy-Efficient EthernetWith lower overall power consumption, the Ethernet switch enhances your energy efficiency, in turn helping you reduce monthly costs.The IES5102 is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage- Network up to 5 Ethernet devices, even in industrial settings, with a robust IP30-rated switch- Wide-range 12-48V DC terminal block input- Easy installation with an integrated DIN rail bracket

Management features
Switch typeUnmanaged
Quality of Service (QoS) supportY
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity5
Basic switching RJ-45 Ethernet ports typeFast Ethernet (10/100)
Network
Networking standardsIEEE 802.1p,IEEE 802.3,IEEE 802.3az,IEEE 802.3u
10G supportN
Full duplexY
Auto MDI/MDI-XY
Auto-negotiationY
Data transmission
Store-and-forwardY
Jumbo frames supportN
Design
Rack mountingY
Product colourBlack
Housing materialPlastic
LED indicatorsActivity,Link,Power
International Protection (IP) codeIP30
Regulatory ApprovalsEN61000-6-2, EN61000-6-4, EN61000-4-3, EN61000-4-4, EN61000-4-6, EN61000-4-8, IEC60068-2-6 Fc, IEC60068-2-27 Ea
Performance
Maximum cable length100 m
Buffer size56 KB
Maximum data transfer rate200 Mbit/s
Mean time between failures (MTBF)1179133 h
Power
Input voltage12 - 48 V
Power consumption (max)2.12 W
Operational conditions
Operating temperature (T-T)-10 - 60 °C
Storage temperature (T-T)-25 - 85 °C
Operating relative humidity (H-H)5 - 95 %
Weight & dimensions
Width25 mm
Depth70 mm
Height110 mm
Weight148 g
Packaging content
ManualY
Packaging data
Terminal block includedY
Package width178 mm
Package depth198 mm
Package height79 mm
Package weight312 g
Certificates
CertificationCE, FCC
Logistics data
Harmonized System (HS) code85176990
