LevelOne GVT-0500 network media converter 10000 Mbit/s Black
(0 review)Add your review
€229,35

LevelOne GVT-0500, 10000 Mbit/s, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet, 10,100,1000,10000 Mbit/s, 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-LX, 1000BASE-SX, 1000BASE-T, 10GBASE-ER, 10GBASE-LR, 10GBASE-SR, 10GBASE-ZR

Availability: In Stock
EAN:4015867209301Categories:NetworkingTags:

The LevelOne GVT-0500 is a powerful 10 Gigabit media converter which, in combination with the optional available LevelOne SFP+ modules, converts optical into electrical signals, supports optical signal equilibrium amplification, clock extraction and optical regeneration. It uses WDM (DWDM/CWDM) technology, which can transmit data signals over a long distance in a single fiber in simple or multiple ways. On existing network infrastructure, the GVT-0500 can quickly improve transmission capacity and expand bandwidth. At the same time, it is a cost-efficent and highly cost-effective solution for managing and operating the system. It is also optimized for ease of operation and maintenance.

Network
Maximum data transfer rate10000 Mbit/s
Networking standardsIEEE 802.3,IEEE 802.3ab,IEEE 802.3ae,IEEE 802.3an,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
Ethernet interface type10 Gigabit Ethernet,Fast Ethernet,Gigabit Ethernet
Ethernet LAN data rates10,100,1000,10000 Mbit/s
Copper ethernet cabling technology10BASE-T,10GBASE-T,100BASE-TX,1000BASE-LX,1000BASE-SX,1000BASE-T
Fiber ethernet cabling technology10GBASE-ER,10GBASE-LR,10GBASE-SR,10GBASE-ZR
Jumbo frames supportY
Jumbo frames9000
Auto MDI/MDI-XY
Duplex systemFull
Cable types supportedCat6a
Performance
Maximum transfer distance100 m
Mean time between failures (MTBF)50000 h
Features
InternalN
Hot-swapY
LED indicatorsActivity,Link,Power
Product colourBlack
Housing materialMetal
Ports & interfaces
Connectivity technologyWired
Ethernet LAN (RJ-45) ports1
Fiber optic connectorSFP
DC-in jackY
Power
Input voltage5 V
Input current3 A
Power consumption (typical)1.2 W
Weight & dimensions
Width115 mm
Depth85 mm
Height25 mm
Weight300 g
Operational conditions
Operating temperature (T-T)-10 - 55 °C
Storage temperature (T-T)-40 - 75 °C
Operating relative humidity (H-H)5 - 90 %
Packaging content
AC adapter includedY
Quick installation guideY
Packaging data
Package width230 mm
Package depth150 mm
Package height85 mm
Package weight700 g
Package typeBox
Certificates
Compliance certificatesRoHS
CertificationCE
Logistics data
Country of originChina
Harmonized System (HS) code85176990
