LevelOne POI-3010 PoE adapter Fast Ethernet, Gigabit Ethernet 52 V
(0 review)Add your review
€39,15

LevelOne POI-3010, Fast Ethernet, Gigabit Ethernet, 10,100,1000 Mbit/s, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, Black, 100 m, PoE, Power

Availability: In Stock
EAN:4015867221815Categories:NetworkingTags:

The LevelOne POI-3010 is a single port, high power PoE PSE solution for remote PoE PD devices. Generating up to 30W , the POI-3010 supplies remote power for new applications such as wireless access points, pan-tilt-zoom (PTZ) IP cameras and videophones. It complies with IEEE 802.3at PoE standard and is backward compatible to IEEE802.3af. It can work with 10/100Base-T networking devices and emerging 1000Base-T devices such as Wi-MAX and wireless IEEE 802.11ac access points. For all the function featured in POI-3010, people can get the benefit of flexible network installation at lower cost and less downtime. It also provides a high-bandwidth pipe to the network.

Network
Ethernet interface typeFast Ethernet,Gigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
Power over Ethernet (PoE)Y
Networking standardsIEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u
Features
Product colourBlack
Wall mountableY
Plug and PlayY
Surge protectionY
Maximum operating distance100 m
LED indicatorsPoE,Power
Pin assignment & polarity1/2 (+), 3/6 (-)
Ports & interfaces
Ethernet LAN (RJ-45) ports2
Power
Power over Ethernet (PoE) voltage52 V
AC adapter input voltage100 - 240 V
AC adapter frequency50/60 Hz
Input current0.8 A
Output current0.6 A
Power consumption (max)30 W
Power over Ethernet (PoE) power per port30 W
Certificates
Compliance certificatesRoHS
CertificationFCC Part 15, CE
Operational conditions
Operating temperature (T-T)0 - 45 °C
Operating relative humidity (H-H)5 - 95 %
Storage temperature (T-T)0 - 70 °C
Storage relative humidity (H-H)5 - 95 %
Weight & dimensions
Width143 mm
Depth51 mm
Height38 mm
Weight350 g
Packaging content
Number of products included1 pc(s)
Power cord includedY
Quick installation guideY
Packaging data
Package width210 mm
Package depth125 mm
Package height55 mm
Package weight400 g
Package typeBox
Logistics data
Harmonized System (HS) code85044095
