LevelOne 16-Port Fast Ethernet PoE Switch, 90W

€195,85

LevelOne 16-Port Fast Ethernet PoE Switch, 90W, Fast Ethernet (10/100), Full duplex, Power over Ethernet (PoE), Wall mountable

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:4015867199831Categories:Networking

FEP-1600 is a 16-port 10/100Mbps Fast Ethernet Switch with Power over Ethernet (PoE) capability. With 16 dip switches, each PoE port can be manually set for On-Off control. FEP-1600 supports up to 30W on each LAN port when the DIP switch is in the ON position . Using a LevelOne PoE repeater, it is possible to extend the connection a further 100 meters, or even daisy-chain several PoE repeaters together for greater distances. Dual 10/100Mbps ports can connect with other edge switches or NVR as uplink ports.- IEEE 802.3x Flow Control protects against lost packets for reliable data transmission- 10/100Mbps, full/half-duplex, auto-negotiation, auto-MDI/MDIX- PoE on/off control per port by dip switches- Simple Plug and Play installation

Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Network
Networking standards	IEEE 802.3,IEEE 802.3u,IEEE 802.3x
10G support	N
Copper ethernet cabling technology	10BASE-T,100BASE-TX
Full duplex	Y
Flow control support	Y
Auto MDI/MDI-X	Y
Auto-negotiation	Y
Data transmission
Switching capacity	3.2 Gbit/s
MAC address table	4000 entries
Store-and-forward	Y
Packet forwarding rate (100 Mbps)	148000 pps
Packet forwarding rate (10 Mbps)	14880 pps
Design
Product colour	Grey
LED indicators	Activity,PoE,Power
Wall mountable	Y
On/off switch	Y
Performance
Buffer size	160 KB
Plug and Play	Y
Power
DC input voltage	56 V
Power consumption (typical)	90 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	82 W
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Storage relative humidity (H-H)	10 - 90 %
Weight & dimensions
Width	188 mm
Depth	118 mm
Height	38 mm
Weight	2100 g
Packaging content
Cables included	AC
Manual	Y
Packaging data
AC adapter included	Y
Package type	Box
Package width	534 mm
Package depth	255 mm
Package height	95 mm
Package weight	2500 g
Certificates
Certification	FCC, CE, RoHS
Logistics data
Country of origin	Taiwan
Master (outer) case width	555 mm
Master (outer) case length	510 mm
Master (outer) case height	280 mm
Harmonized System (HS) code	85176990
Master (outer) case gross weight	13500 g
Products per master (outer) case	5 pc(s)
