LevelOne PoE over Hybrid Cable Receiver, 4 PoE Outputs, Indoor/Outdoor
LevelOne PoE over Hybrid Cable Receiver, 4 PoE Outputs, Indoor/Outdoor, Network receiver, 2000 m, 100 Mbit/s, Full, Half, 1000 entries, 14880 pps
Availability: In Stock
Using hybrid fiber and copper cable, the LevelOne PFE range can deliver integrated power and data over a distance of 6,800 ft (2km) to a receiver which provides high-power PoE output for IP surveillance applications. A tough outdoor range (PFE-1011/1014) provides the same performance within a durable IP66-rated waterproof housing for harsh environmental conditions and temperature range of -40°C to 60°C.- Extend data and power up to 2km via a single Hybrid Fiber Cable- Enable PoE devices to distant remote location- Supporting high power consumption devices (up to 60W at 450m link)- Flexible installation option - 1 or 4 PoE output receivers selectable- Outdoor casing protects operation under wide temperature range (PFE-1011R/1014R)- Outdoor weatherproof models are sustainable from water and dust (PFE-1011R/1014R)
| Performance | |
|---|---|
| Type | Network receiver |
| Maximum transfer distance | 2000 m |
| Data transfer rate | 100 Mbit/s |
| Auto MDIX IEEE | Y |
| Duplex system | Full,Half |
| MAC address table | 1000 entries |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet forwarding rate (100 Mbps) | 148000 pps |
| Flow control support | Y |
| International Protection (IP) code | IP66 |
| Network | |
| Cabling technology | 10/100Base-T(X) |
| Networking standards | IEEE 802.3,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 4 |
| Power over Ethernet (PoE) ports quantity | 4 |
| Fiber optic connector | LC |
| Fiber ports quantity | 1 |
| Terminal block port | Y |
| Design | |
| Product colour | Grey |
| Mounting type | Wall |
| LED indicators | LAN,PoE,Power |
| Country of origin | Taiwan |
| Certification | CE/FCC |
| Power | |
| Power consumption (typical) | 20 W |
| Power consumption (max) | 60 W |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) voltage range | 47 - 56 V |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | 0 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 5 - 90 % |
| Weight & dimensions | |
| Width | 240 mm |
| Depth | 200 mm |
| Height | 72 mm |
| Weight | 1000 g |
| Packaging content | |
| Cables included | AC |
| Quick start guide | Y |
| Packaging data | |
| Package type | Box |
| Package width | 250 mm |
| Package depth | 210 mm |
| Package height | 85 mm |
| Package weight | 200 g |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
