LevelOne 1.25Gbps Single-mode Industrial SFP Transceiver, 10km, 1310nm, -40°C to 85°C

€25,67

LevelOne 1.25Gbps Single-mode Industrial SFP Transceiver, 10km, 1310nm, -40°C to 85°C, Fiber optic, 1250 Mbit/s, SFP, LC, 9/125 µm, 10000 m

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:4015867181034Categories:Networking

LevelOne SFP-4210 is a high performance and cost-effective single-mode SFP transceiver. Intended for use with Gigabit Ethernet, it provides up to 1.25 Gbps bidirectional data transfer rate on a single duplex fiber core. For use with 9 and 125 micron fiber cables, it can reach a distance of up to 10km. The SFP-4210 transceiver operates using a wavelength of 1310nm with a FP Laser Diode light source and has an LC port.This Hot-swappable SFP transceiver offers the latest Industrial standard in full-duplex Ethernet connectivity and withstand under wide range temperature operation.

Performance
SFP transceiver type	Fiber optic
Maximum data transfer rate	1250 Mbit/s
Interface type	SFP
Single-mode fiber (SMF) supported	Y
Multi-mode fiber (MMF) supported	N
Fiber optic connector	LC
Fiber cable diameters supported (core/cladding)	9/125 µm
Maximum transfer distance	10000 m
Wavelength	1310 nm
Tx power (min)	-9.5 dBmW
Tx power (max)	-3 dBmW
Rx power (min)	-25 dBmW
Rx power (max)	2 dBmW
Networking standards	IEEE 802.3z
Copper ethernet cabling technology	1000BASE
Duplex system	Full
Digital Diagnostics Monitoring (DDM)	Y
Features
Product colour	Silver
Hot-swap	Y
Power
Maximum voltage	3.47 V
Maximum current	0.3 A
Power consumption (typical)	0.8 W
Certificates
Compliance certificates	RoHS
Certification	CE, FCC
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	0 - 85 %
Weight & dimensions
Width	14 mm
Depth	57 mm
Height	12 mm
Weight	20 g
Packaging content
Quantity per pack	1 pc(s)
Packaging data
User guide	Y
Package width	65 mm
Package depth	106 mm
Package height	20 mm
Package weight	39 g
Package type	Box
Logistics data
Pallet gross length	800 mm
Pallet gross width	1200 mm
Pallet height (air)	1669 mm
Products per pallet	35 pc(s)
Master (outer) case width	310 mm
Master (outer) case length	375 mm
Harmonized System (HS) code	85369010
Master (outer) case height	268 mm
Master (outer) case gross weight	6670 g
Products per master (outer) case	150 pc(s)
Country of origin	China
