Zalman ZM650-GVII power supply unit 650 W 20+4 pin ATX ATX Black
€45,27
Zalman ZM650-GVII, 650 W, 200 - 240 V, 50 - 60 Hz, 6 A, Active, 110 W
Availability: In Stock
80 Plus Bronze 230V EU certified Power Supply Unit. It supplies smooth power to the PC while reducing unnecessary power consumption by using high-performance parts that are very durable and reliable.
| Power | |
|---|---|
| Total power | 650 W |
| AC input voltage | 200 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 6 A |
| Power factor | 99 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 110 W |
| Combined power (+12V) | 648 W |
| Combined power (+5V) | 110 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 54 A |
| Max output current (+5V) | 18 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| Efficiency | 88 % |
| Power protection features | Over current,Over power,Over voltage,Short circuit,Under voltage |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 550 mm |
| Number of SATA power connectors | 2 |
| SATA power cable length | 400 mm |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| Peripheral (Molex) power cable length | 400 mm |
| PCI Express power connectors (6+2 pin) | 2 |
| PCI Express power cable length | 500 mm |
| CPU power connector (4+4 pin) | Y |
| CPU power cable length | 650 mm |
| ATX power connector (20+4 pin) | Y |
| PCI Express connector | Y |
| Cabling type | Non-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Bronze |
| Supported motherboard form factors | ATX,Micro ATX,Mini-ATX |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| Noise level | 36.3 dB |
| Bearing technology | FDB |
| Mean time between failures (MTBF) | 100000 h |
| Design | |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 120 mm |
| Number of fans | 1 fan(s) |
| Fan location | Top |
| On/off switch | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 85 % |
| Storage relative humidity (H-H) | 5 - 95 % |
| Packaging content | |
| Cables included | AC,CPU,PCIe,Peripheral (Molex),SATA |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | 80 Plus, CB, CE, KC, EAC, RoHS |
| Safety regulation & standards | |
| Safety | CB, CE, KC, EAC, RoHS |
| Weight & dimensions | |
| Width | 140 mm |
| Depth | 150 mm |
| Height | 86 mm |
| Weight | 2010 g |
| Packaging data | |
| Package width | 180 mm |
| Package depth | 280 mm |
| Package height | 100 mm |
| Package weight | 2050 g |
| Package type | Box |
| Logistics data | |
| Country of origin | China |
