D-Link 10-Port Gigabit PoE+ Nuclias Smart Managed Switch including 2x SFP Ports
(0 review)Add your review
€310,15

D-Link 10-Port Gigabit PoE+ Nuclias Smart Managed Switch including 2x SFP Ports, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting

Availability: In Stock
EAN:0790069442933Categories:NetworkingTags:

Cloud Networking, RefreshedThe DBS-2000 series of switches is part of the Nuclias Cloud solution – D-Link’s complete Cloud-Managed Networking solution for Small-to-Medium Businesses (SMBs), designed to make the ownership and administration of your IT infrastructure as simple and hassle-free as possible.Management Over the CloudDBS-2000 is a series of Smart Managed Switches, manageable via the Nuclias Cloud Web Portal through any compatible online PC or Tablet. Connectivity with the Nuclias Cloud platform is guaranteed, with a 99.9% Service-Level-Agreement (SLA), and operation will continue even if the Cloud connection fails.Easy TroubleshootingThe DBS-2000 Series features Cable Diagnostics and Per Port Traffic Packet Counters to help network admins find & solve network problems. Cable Diagnostics enables quick examination of cable quality, recognition of cable type, and detection of cable errors, with the Per-Port Traffic Packet Counter helping to further isolate problems.Advanced Security FeaturesThe DBS-2000 series utilizes the Nuclias Cloud Web Portal interface, giving administrators an easy way to manage Layer-2 features, such as VLANs, Spanning Tree Protocol (STP), and 802.3ad Link Aggregation (static). With powerful security features, including IGMP snooping, Static MAC, and end-to-end encryption (WPA/WPA2/WPA3), these Cloud switches are a versatile solution for deployments that require easy configuration, without added complexities.Full PoE SupportSelect models in the DBS-2000 Series support Power over Ethernet (PoE) for copper access ports. Power over Ethernet greatly simplifies the installation of PoE-enabled devices such as VoIP phones and IP cameras in remote locations with no immediate access to a power outlet.

Management features
Switch typeManaged
Switch layerL2
Web-based managementY
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Combo SFP ports quantity2
Console portRJ-45
Network
Networking standardsIEEE 802.3ad,IEEE 802.3at
10G supportN
Copper ethernet cabling technology10BASE-T,100BASE-TX,1000BASE-T
Link aggregationY
Auto MDI/MDI-XY
Spanning tree protocolY
Data transmission
Switching capacity20 Gbit/s
Forwarding rate14.88 Mpps
Packet buffer memory4.1 MB
Security
IGMP snoopingY
Security algorithmsWPA3,WPA,WPA2
Design
Rack mountingY
Product colourGrey
LED indicatorsY
Number of fans0 fan(s)
Performance
Built-in processorY
Processor frequency500 MHz
Memory typeDDR3-SDRAM
Internal memory256 MB
Flash memory32 MB
Mean time between failures (MTBF)1274005 h
Power
AC input voltage100 - 240 V
Power consumption (max)152.3 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)Y
Power over Ethernet plus (PoE+) ports quantity8
Power over Ethernet (PoE) power per port30 W
Total Power over Ethernet (PoE) budget130 W
Operational conditions
Operating temperature (T-T)-5 - 50 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)0 - 95 %
Storage relative humidity (H-H)0 - 95 %
Operating altitude0 - 1500 m
Heat dissipation519.51 BTU/h
Weight & dimensions
Width330 mm
Depth180 mm
Height44 mm
Weight1770 g
Packaging data
Package width319 mm
Package depth400 mm
Package height91 mm
Package weight3386 g
Technical details
Shipping (inner) case height349 mm
Shipping (inner) case width294 mm
Shipping (inner) case length416 mm
Shipping (inner) case net weight10158 g
Products per shipping (inner) case3 pc(s)
Pallet gross weight (air)282540 g
Master (outer) cases per pallet (air)24 pc(s)
Products per pallet (air)72 pc(s)
Pallet gross length1100 mm
Pallet gross width1200 mm
Pallet height (air)1182 mm
Pallet gross weight (sea)458400 g
Master (outer) cases per pallet (sea)40 pc(s)
Products per pallet (sea)120 pc(s)
Pallet height (sea)1880 mm
Shipping (inner) case gross weight10960 g
Logistics data
Harmonized System (HS) code85176990
