Viewsonic PA503W data projector Standard throw projector 3800 ANSI lumens DMD WXGA (1280x800) White

(0 review)Add your review

€428,96

Viewsonic PA503W, 3800 ANSI lumens, DMD, WXGA (1280x800), 22000:1, 762 - 7620 mm (30 - 300"), 1 - 10.98 m

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:0766907904918Categories:Monitors & Projectors

DescriptionThe ViewSonic PA503W price-performance projector features 3,600 lumens, native WXGA 1280x800 resolution, and an intuitive, user-friendly design. Exclusive SuperColor technology offers a wider color range for lifelike image projection. The PA503w also features extensive connectivity including HDMI, 2 x VGA in, Composite Video, 1 x VGA output, and Audio in/out. An energy-saving SuperEco feature reduces power consumption by up to 70%, and extends the lamp life by up to 10,000 hours. With advanced audiovisual features, flexible connectivity options, and an affordable price, the PA503W is ideal for use in education and small business environments.

Projector
Screen size compatibility	30 - 300 "
Projection distance	1 - 10.98 m
Projector brightness	3800 ANSI lumens
Projection technology	DMD
Projector native resolution	WXGA (1280x800)
Contrast ratio (typical)	22000:1
Number of colours	1.07 billion colours
Horizontal scan range	15 - 102 kHz
Vertical scan range	23 - 120 Hz
Keystone correction, vertical	-40 - 40 °
Matrix size	0.65 "
Light source
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	15000 h
Lamp power	200 W
Lamps quantity	1 lamp(s)
Lens system
Focus	Manual
Focal length range	22 - 24.1 mm
Aperture range (F-F)	2.56 - 2.68
Zoom capability	Y
Zoom ratio	2.0:1
Throw ratio	1.55-1.7
Offset	100 %
Video
Analog signal format system	NTSC,PAL,SECAM
Supported graphics resolutions	640 x 480 (VGA),1920 x 1080 (HD 1080)
Supported video modes	480i,480p,576i,576p,720p,1080i,1080p
Ports & interfaces
HDMI connector type	Full-size
HDMI version	1.4
Mini-USB 2.0 ports quantity	1
Serial interface type	RS-232
PC Audio in	Y
PC Audio out	Y
VGA (D-Sub) ports quantity	3
HDMI ports quantity	1
Composite video in	1
DVI port	N
Mobile High-Definition Link (MHL)	N
AC (power) in	Y
Network
Smart TV	N
Ethernet LAN	N
Wi-Fi	N
Storage
Card reader integrated	N
Features
Interactive	N
Noise level (economic mode)	27 dB
HDCP	Y
On Screen Display (OSD)	Y
On Screen Display (OSD) languages	ARA,CHI (SIMPL),CHI (TR),CZE,DEU,DUT,ENG,ESP,FIN,FRE,GRE,IND,ITA,JPN,KOR,POL,POR,RUS,SWE,THA,TUR,VIE
Number of OSD languages	22
Noise level	31 dB
Multimedia
Built-in speaker(s)	Y
RMS rated power	2 W
Design
Market positioning	Presentation
Product type	Standard throw projector
Product colour	White
Placement	Desktop,Ceiling
Display
Built-in display	N
Power
Power source	AC
Power consumption (typical)	260 W
Power consumption (standby)	0.5 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Weight & dimensions
Width	294 mm
Depth	218 mm
Height	110 mm
Weight	2220 g
Package width	365 mm
Package depth	300 mm
Package height	188 mm
Package weight	3240 g
Packaging content
Remote control included	Y
Cables included	AC,VGA
Manual	Y
Logistics data
Pallet gross length	740 mm
Pallet gross width	900 mm
Pallet gross height	2210 mm
Products per master (outer) case	1 pc(s)
Harmonized System (HS) code	8528620000
