ATEN 16-Port CAT5e/6 KVM Over IP Switch
(0 review)Add your review
€756,01

ATEN 16-Port CAT5e/6 KVM Over IP Switch, 1920 x 1200 pixels, Ethernet LAN, WUXGA, 8.9 W, Black

Availability: Arriving Soon
EAN:4710423777446Categories:NetworkingTags:aten, kvm switches, 16, port, cat5e, 6

The KH1516Ai Cat 5 High-Density KVM over IP Switch offers 16 computer port configurations in a 1U-high housing for convenient rack mounting. They allow local and remote operators to monitor and access the entire enterprise data center over the Internet using a web-based browser. The KH1516Ai features RJ-45 connectors and Cat 5e/6 cable to link to the computers and supports multiplatform. This ensures that high quality signals can travel over long distance- up to 50m without the need for KVM extenders. Utilizing KVM Adapter Cables for the final linkup, the KH1508Ai permits any combination of PCs, Macs, Sun computers, and serial devices to coexist on the installation. In addition to TCP/IP connectivity, the KH1516Ai provides console ports for a locally attached USB or PS/2 console and a Laptop USB console (LUC) – allowing access and control from the data center as well as over the Net.1x KH1516Ai Cat 5 High-Density KVM over IP Switch1x Firmware Upgrade Cable1x LIN6-04U1-M18G Laptop USB Console Cable USB-A to Micro USB-B 1x LIN2-481K-E12G Power Cord1x Rack Mount Kit1x Foot Pad Set (4 pcs.)1x User Instructions

Ports & interfaces
Number of computers controlled16
Keyboard port typeUSB, PS/2
Mouse port typeUSB, PS/2
Video port typeVGA
Console portsPS/2,USB A,VGA (D-Sub)
Console USB ports quantity2
USB connector typeUSB Type-A
PS/2 ports quantity2
Network
Ethernet LANY
Ethernet LAN (RJ-45) ports16
Performance
HD typeWUXGA
Maximum resolution1920 x 1200 pixels
Video bandwidth60 Hz
Scan interval1,255 s
Design
Product colourBlack
Housing materialMetal
LED indicatorsY
Push buttonY
Hot keysY
Display
Built-in displayN
Power
Power sourceAC
Input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current1 A
Power consumption (typical)8.9 W
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80 %
Storage relative humidity (H-H)0 - 80 %
Weight & dimensions
Width437.2 mm
Depth163.6 mm
Height44 mm
Weight3140 g
Packaging data
Package width131 mm
Package depth540 mm
Package height233 mm
Package weight3630 g
Packaging content
Quick installation guideY
ManualY
Logistics data
Master (outer) case net weight9420 g
Harmonized System (HS) code85176200
Master (outer) case width420 mm
Master (outer) case length565 mm
Master (outer) case height258 mm
Master (outer) case gross weight11570 g
Products per master (outer) case3 pc(s)
