Epson EB-685W Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White, Grey
(0 review)Add your review
€879,20

Epson EB-685W, 3500 ANSI lumens, 3LCD, WXGA (1280x800), 14000:1, 16:10, 1524 - 2540 mm (60 - 100")

Availability:: Arriving soon
EAN:8715946605210Categories:Monitors & Projectors

HD-ready classroom projectorInnovative teaching solution with a large scalable screen size of up to 100 inches to display HD-ready WXGA content for enhanced learning.The EB-685W's ultra-short-throw design allows you to present large images from a very short distance with minimised shadows and glare. With a brightness level of 3,500 lumens, an HD-ready WXGA resolution, a 14,000:1 contrast ratio, and HDMI input, students benefit from sharp, clear images.High-quality, bright imagesEpson’s 3LCD technology ensures high-quality images with equally high White and Colour Light Output for vivid colours and bright images, even in daylight, and three times brighter colours than leading competitive projectors.Enhanced learningSplit-screen functionality allows two pieces of content to be displayed simultaneously without compromising on quality. The moderator function allows teachers to remain in control, choosing what content to display.Document camera compatibilityConnecting the optional Epson document camera allows you to easily display images and 3D objects with incredible detail for the whole class to see.Keep costs downProject for longer with improved reliability and a longer lamp life of up to 10,000 hours in eco mode.-Optional wireless capabilityWirelessly display content easily from a range of smart devices and Google Chromebooks using our iProjection App.

Projector
Supported aspect ratios16:10
Screen size compatibility60 - 100 "
Projection distance0.4 - 0.6 m
Projection distance (wide)0 - 0.4 m
Projection distance (tele)0 - 0.6 m
Contrast ratio (dynamic)14000:1
Projector brightness3500 ANSI lumens
Projection technology3LCD
Projector native resolutionWXGA (1280x800)
Contrast ratio (typical)14000:1
Native aspect ratio16:10
Number of colours1.07 billion colours
Projector brightness (economic mode)2900 ANSI lumens
Vertical scan range100 - 120 Hz
Keystone correction, horizontal-3 - 3 °
Keystone correction, vertical-3 - 3 °
Matrix size0.59 "
Light source
Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)10000 h
Lamp power250 W
Lens system
FocusManual
Focal length range3.7 mm
Fixed focal length3.7 mm
Zoom capabilityY
Zoom typeAuto
Zoom ratio1.35:1
Digital zoom1.35 x
Throw ratio0.28 - 0.37:1
Video
Full HDN
HD-ReadyY
3DN
Video processing10 bit
Colour modes (2D)Cinema,Dynamic
Video colour modesDynamic,Cinema,Presentation,sRGB,Blackboard
Ports & interfaces
USB 2.0 ports quantity2
Audio (L/R) in1
Headphone outputs1
Microphone inY
Serial interface typeRS-232
VGA (D-Sub) ports quantity3
HDMI ports quantity3
USB connector typeUSB Type-A,USB Type-B
Composite video in1
DVI portN
Mobile High-Definition Link (MHL)Y
AC (power) inY
Network
Ethernet LANY
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100 Mbit/s
Storage
Card reader integratedN
Features
InteractiveN
Noise level (economic mode)30 dB
On Screen Display (OSD)Y
Noise level35 dB
Air filterY
2D/3D frequency image100 - 120 Hz
Country of originPhilippines
Password protectionY
Compatible operating systemsLinux, Mac OS 10.10.x, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, Ubuntu 16.04 LTS, Windows 10, Windows 8, Windows 8.1
Multimedia
Built-in speaker(s)Y
RMS rated power16 W
Number of built-in speakers1
Design
Market positioningUlta short throw
Product typeUltra short throw projector
Product colourWhite,Grey
PlacementWall
Cable lock slotY
Cable lock slot typeKensington
Display
Built-in displayN
Power
Power sourceAC
Power consumption (typical)354 W
Power consumption (standby)0.37 W
Power consumption (PowerSave)310 W
Power consumption (economy mode)309 W
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Software
Software supportvia: AMX, Crestron (Network), Control4
Windows operating systems supportedWindows 10,Windows 8,Windows 8.1
Mac compatibilityY
Mac operating systems supportedMac OS X 10.7 Lion,Mac OS X 10.8 Mountain Lion,Mac OS X 10.9 Mavericks
Operational conditions
Operating temperature (T-T)5 - 40 °C
Storage temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)20 - 80 %
Storage relative humidity (H-H)10 - 90 %
Weight & dimensions
Width367 mm
Depth400 mm
Height149 mm
Weight5700 g
Package width490 mm
Package depth730 mm
Package height335 mm
Package weight18483 g
Packaging content
Remote control includedY
Remote control typeIR
Batteries includedY
Cables includedAC
Quick start guideY
ManualY
WLAN adapter includedY
Bundled softwareEasyMP Multi PC Projection, Epson Projektor Management
Technical details
ColourY
USB display function3 in 1: Image / Mouse / Sound
Sustainability certificatesTCO
Logistics data
Quantity per pack1 pc(s)
Products per pallet12 pc(s)
Pallet gross weight0 g
Pallet gross length1200 mm
Pallet gross width800 mm
Pallet gross height1410 mm
Products per pallet layer2 pc(s)
Products per pallet layer (UK)2 pc(s)
Products per pallet (UK)12 pc(s)
Pallet weight (UK)0 g
Pallet length (UK)1200 mm
Pallet width (UK)1000 mm
Pallet height (UK)1410 mm
Harmonized System (HS) code85286200
Other features
RS-232 ports1
