Hannspree Open Frame HO 225 HTB Totem design 54.6 cm (21.5") LED 250 cd/m² Full HD Black Touchscreen 24/7
Hannspree Open Frame HO 225 HTB, Totem design, 54.6 cm (21.5"), LED, 1920 x 1080 pixels, 24/7
Availability:: Arriving soon
- 1920 x 1080 WUXGA Resolution Full HD 1080p- 10-Point Touch P-Cap Technology- 178° / 178° Ultra Wide Viewing Angle- Tripple Input; HDMI + DVI-D + VGA- High Contrast Ratio 3000:1- 300cd/m2 High Brightness- 24/7 Operating- 50000 Hours Backlight Lifetime- 12 Volt External Power Supply- Multiple Mounting Options- 7H Toughened Hard Panel Surface- Low Power Consumption & Multi-Video Modes- Slim Profile with Narrow EdgesOpen Frame solutions for the amusement and entertainment sectors in a variety of sizes.With the support of highly experienced, vertical manufacturing capabilities, our Open Frame monitor business is designed to provide a cost effective, "one stop solution" for project requirements. We already supply Open Frame solutions for a number of large gaming tenders across Europe.Choose from standard or touch screen high performance displays ranging from 19" up to 27" and the right aspect ratio to best fit your application. Offering a completely flexible, personal service HannsG by Hannspree delivers customised solutions to fulfil the specific demands of both OEMs and System Integrators.Our display supports rear and VESA mount for multiple mounting options and together with integrated brackets provides the benefits of easy installation, and flexibility for different applications.
| Display | |
|---|---|
| Display diagonal | 21.5 " |
| Display technology | LED |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 250 cd/m² |
| HD type | Full HD |
| Touchscreen | Y |
| Number of simultaneous touchpoints | 10 |
| Multi-touch | Y |
| Native aspect ratio | 16:9 |
| Response time | 18 ms |
| Contrast ratio (typical) | 3000:1 |
| Contrast ratio (dynamic) | 10000000:1 |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.24795 x 0.24795 mm |
| Active display area (W x H) | 476 x 268 mm |
| Display diagonal (metric) | 54.6 cm |
| Panel life | 30000 h |
| Horizontal scan range | 31.5 - 80 kHz |
| Vertical scan range | 60 - 75 Hz |
| Hardness | 6H |
| Transparency | 85 % |
| Ports & interfaces | |
| HDMI ports quantity | 1 |
| DVI port | N |
| VGA (D-Sub) input ports | 1 |
| USB port | Y |
| USB ports quantity | 1 |
| PC Audio in | Y |
| Audio | |
| Built-in speaker(s) | Y |
| Number of built-in speakers | 2 |
| RMS rated power | 3 W |
| Design | |
| Product design | Totem design |
| Placement supported | Indoor |
| Product colour | Black |
| VESA mounting | Y |
| Panel mounting interface | 100 x 100 mm |
| Performance | |
| TV tuner integrated | N |
| On Screen Display (OSD) | Y |
| Number of OSD languages | 8 |
| Operating hours (hours/days) | 24/7 |
| HDCP | N |
| International Protection (IP) code | IP65 |
| Power | |
| Power consumption (typical) | 13.94 W |
| Power consumption (standby) | 0.16 W |
| Power consumption (off) | 0.15 W |
| Energy efficiency class (SDR) | F |
| Energy consumption (SDR) per 1000 hours | 20 kWh |
| External power adapter | Y |
| Energy efficiency scale | A to G |
| Computer system | |
| Computer system | N |
| Built-in processor | N |
| Weight & dimensions | |
| Display width | 526.8 mm |
| Display depth | 44 mm |
| Display height | 324.6 mm |
| Display weight | 5100 g |
| Packaging data | |
| Package width | 603 mm |
| Package depth | 88 mm |
| Package height | 415 mm |
| Package weight | 6300 g |
| Packaging content | |
| Cables included | AC,HDMI,USB |
| Warranty card | Y |
| Certificates | |
| Certification | CE |
| Logistics data | |
| Harmonized System (HS) code | 85285210 |
| Network | |
| Ethernet LAN | N |
| Wi-Fi | N |
| Technical details | |
| Sustainability certificates | RoHS |
| Compliance certificates | RoHS |
| Other features | |
| Quick start guide | Y |
| Glass protection | Y |
