D-Link 10GBase-LR SFP+ Transceiver, 10km
D-Link 10GBase-LR SFP+ Transceiver, 10km, Fiber optic, 10000 Mbit/s, SFP+, LC, 9/125 µm, LR
Availability: Arriving Soon
D-Link’s 10G SFP+ Module series are hot-swappable SFP+ transceivers that plug into SFP+ slots on switches and support 10G Ethernet. The D-Link 10GBASE SFP+ Module Series transceivers offer customers a wide variety of 10G Ethernet connectivity options for data centers, enterprise wiring closets, and service provider transport applications.Enhanced Small Form-factor Pluggable FormatThe transceivers use the Enhanced Small Formfactor Pluggable format (SFP+). The SFP+ form factor is smaller than other form factors such as Xenpak, X2, and 10G XFP, ensuring lower costs, lower power disruption, and higher port density. They provide the necessary signal amplification for data to be transmitted to the network cable from the port, and vice versa, for the port to receive data from the network cable. Hot PluggableAll D-Link transceivers are hot-pluggable. You can connect a transceiver while the system is powered on without causing any problems. This permits modules to be added or removed without interrupting the network. 10G Ethernet speedsThe transceivers all support 10G Ethernet, which results in very fast data transmissions of up to 10 Gbit/s. This is 10 times faster than Gigabit Ethernet and enables the switch to handle faster and higher data transmissions, making it very suitable for business needs.
| Performance | |
|---|---|
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 10000 |
| Interface type | SFP+ |
| Single-mode fiber (SMF) supported | Y |
| Multi-mode fiber (MMF) supported | N |
| Fiber optic connector | LC |
| Fiber cable diameters supported (core/cladding) | 9/125 |
| SFP transceiver standard | LR |
| Maximum transfer distance | 10000 |
| Wavelength | 1310 |
| Tx power (min) | -8.5 |
| Tx power (max) | 0.5 |
| Rx power (min) | -12.6 |
| Rx power (max) | 0.5 |
| Link budget | 10.1 |
| Networking standards | IEEE 802.3ae |
| Fiber ethernet cabling technology | 10GBASE |
| Duplex system | Full |
| Features | |
| Product colour | Gold,Metallic |
| Hot-Plug support | Y |
| Mean time between failures (MTBF) | 4650000 |
| Power | |
| Maximum voltage | 3.3 |
| Maximum current | 300 |
| Certificates | |
| Compliance certificates | RoHS |
| Safety | UL, TUV, CDRH |
| Certification | CE, FCC, VCCI, MSA |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 |
| Storage temperature (T-T) | -40 - 85 |
| Operating relative humidity (H-H) | 5 - 85 |
| Storage relative humidity (H-H) | 5 - 95 |
| Weight & dimensions | |
| Width | 14.8 |
| Depth | 11.85 |
| Height | 56.5 |
| Weight | 19.5 |
| Packaging data | |
| Package width | 74 |
| Package depth | 131 |
| Package height | 49 |
| Package weight | 64 |
| Logistics data | |
| Shipping (inner) case length | 360 |
| Shipping (inner) case width | 260 |
| Shipping (inner) case height | 310 |
| Shipping (inner) case net weight | 3200 |
| Products per shipping (inner) case | 50 |
| Pallet gross weight (air) | 272000 |
| Master (outer) cases per pallet (air) | 60 |
| Products per pallet (air) | 3000 |
| Pallet gross length | 1020 |
| Pallet gross width | 1220 |
| Pallet height (air) | 1990 |
| Pallet gross weight (sea) | 272000 |
| Master (outer) cases per pallet (sea) | 60 |
| Products per pallet (sea) | 3000 |
| Pallet height (sea) | 1990 |
| Shipping (inner) case gross weight | 4200 |
| Harmonized System (HS) code | 85369010 |
