D-Link DEM-211 network transceiver module Fiber optic 100 Mbit/s SFP 1310 nm
(0 review)Add your review
€69,78

D-Link DEM-211, Fiber optic, 100 Mbit/s, SFP, LC, 50/125,62.5/125 µm, 2000 m

Availability: Arriving Soon
EAN:0790069298127Categories:NetworkingTags:

D-Link's DEM-210 and DEM-211 SFP transceivers provide a high performance solution for serial optical data communication applications. They are hot-swappable, Small Form Factor Pluggable (SFP) compliant with the Multi-Source Agreement (MSA) specification. The transceivers have duplex LC connectors and provide IEEE 802.3u compliant link for up to 100Mbps in the half duplex mode (or 200Mbps full-duplex mode) transmission for fiber cable applications.D-Link's highly integrated transceivers offer low jitter performance for extended optical links support without performance degradation. This high performance enables reliable data transfer in short-, intermediate- and long-distances for building, factory, campus and metropolitan networking applications.Previous combo-port switch designs have only provided Gigabit copper or SFP fiber-optic connectivity but not 100BASE-FX SFP fiber-optic connectivity. Switch designs like the DES-1226G and DES-3526 are of the former type. D-Link now provides 100BASE-FX SFP fiberoptic connectivity on Gigabit combo SFP ports for new switch model designs. Futher, in our effort to offer a full product porfolio, D-Link has developed the DEM-210 100BASE-FX SFP transceiver which can plug-in to the Gigabit combo SFP fiber-optic slot of selected switches to provide 100BASE-FX connectivity.The transceiver connects with certain specific supported D-Link switches. It is not for use in the Gigabit SFP fiber-optic ports found in other switches. The current list of D-Link switches that support the new module includes the following: DES-1228, DES-1228P, DES-1252, DHS-3028, DHS-3628F, DHS-3626F, DGS-3612G.

Performance
SFP transceiver typeFiber optic
Maximum data transfer rate100
Interface typeSFP
Multi-mode fiber (MMF) supportedY
Fiber optic connectorLC
Fiber cable diameters supported (core/cladding)50/125,62.5/125
Maximum transfer distance2000
Wavelength1310
Link budget13
Networking standardsIEEE 802.3u
Cabling technology100Base-FX
Fiber ethernet cabling technology100BASE
Duplex systemFull,Half
Features
Product colourMetallic
Form factorPlug-in
Hot-swapY
Compatible productsDES-1228, DES-1228P, DES-3252P, DES-3228PA, DES-1252, DGS-3612G
Power
Maximum voltage3.3
Certificates
SafetyFDA/CDRH, TUV, UL
CertificationRoHS
Operational conditions
Operating temperature (T-T)0 - 70
Storage temperature (T-T)-40 - 85
Operating relative humidity (H-H)10 - 90
Storage relative humidity (H-H)5 - 90
Weight & dimensions
Width57.912
Depth12.7
Height7.62
Weight13.6
Packaging data
Package width74
Package depth131
Package height49
Package weight64
Logistics data
Shipping (inner) case length360
Shipping (inner) case width260
Shipping (inner) case height310
Shipping (inner) case net weight3200
Products per shipping (inner) case50
Pallet gross weight (air)246800
Master (outer) cases per pallet (air)54
Products per pallet (air)2700
Pallet gross length1020
Pallet gross width1220
Pallet height (air)1990
Pallet gross weight (sea)246800
Master (outer) cases per pallet (sea)54
Products per pallet (sea)2700
Pallet height (sea)1990
Shipping (inner) case gross weight4200
Harmonized System (HS) code85369010
