LevelOne 8-Port Gigabit PoE Switch, 802.3at/af PoE, 123.2W
(0 review)Add your review
€270,23

LevelOne 8-Port Gigabit PoE Switch, 802.3at/af PoE, 123.2W, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Rack mounting

Availability: In Stock
EAN:4015867163849Categories:NetworkingTags:

The LevelOne GEP-0821 provides 8 x 10/100/1000Mbps ports with IEEE 802.3at PoE plus supported. This switch is IEEE 802.3af/at compliant, and provides power and data over a single Ethernet cable to any PoE device, with total power budget of 123.2W, up to 30W per port. Together with Energy Efficient Ethernet (IEEE 802.3az) standard compliant, it substantially lower power consumption during periods of low-link utilization. Moreover, supports Gigabit Ethernet connectivity with 9K jumbo frames for network performing enhancement. Ideal for small businesses that prefer an affordable solution for PoE deploying infrastructure.- IEEE 802.3af/at PoE compliant to simplify deployment and installation- 10/100/1000Mbps wire speed transmission and reception- 9K jumbo frames to increase data transfer rates- Supports 8K MAC address auto-learning and auto-aging- Auto-detection and protection of non-standard PoE devices- IEEE 802.3x Flow Control protects against lost packets for reliable data transmission- 19-inch rackmount kit included- Total PoE power budget: 123.2W, up to 30W per port- Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az)

Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Power connectorDC-in jack
Network
Networking standardsIEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x
Copper ethernet cabling technology10BASE-T,100BASE-TX,1000BASE-TX
Cable types supportedCat5,Cat6,Cat7
Full duplexY
Flow control supportY
Data transmission
Switching capacity16 Gbit/s
MAC address table8192 entries
Store-and-forwardY
Jumbo frames supportY
Jumbo frames9000
Packet forwarding rate (1 Gbps)1488000 pps
Packet forwarding rate (100 Mbps)148000 pps
Packet forwarding rate (10 Mbps)14880 pps
Design
Rack mountingY
Product colourGrey
LED indicatorsActivity,PoE
Performance
Buffer size128 KB
Power
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current2 A
Power consumption (typical)130 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)Y
Power over Ethernet plus (PoE+) ports quantity8
Total Power over Ethernet (PoE) budget123.3 W
Operational conditions
Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90 %
Storage relative humidity (H-H)10 - 90 %
Weight & dimensions
Width280 mm
Depth185 mm
Height44 mm
Weight2000 g
Packaging content
Cables includedAC
Quick start guideY
Packaging data
Package typeBox
Package width371 mm
Package depth230 mm
Package height82 mm
Package weight2260 g
Certificates
CertificationFCC, CE
Logistics data
Country of originTaiwan
Harmonized System (HS) code85176990
