Fujitsu CP400I RAID controller PCI Express x8 3.0 12 Gbit/s
Fujitsu CP400I, SAS, Serial ATA, PCI Express x8, 0, 1, 12 Gbit/s, 0 - 55 °C, -45 - 105 °C
Availability:: Arriving soon
The PSAS CP400i, eight port SAS/SATA host bus adapter provides increased connectivity and maximum performance for high-end servers and applications within internal and external storage. Performance is based on the LSI SAS3008 IO controller, integrating the latest enhancements in SAS and PCI Express 3.0 technology.- 12Gb/s data transfer rate per port;- 12Gb/s SAS connectivity eases integration and broadens application by supporting legacy speeds and the SATA protocol;- Two x4 internal SFF8643 (Mini-SAS HD) connectors;- Doubles the performance of previous generation SATA+SAS HBAs;- LSI SAS3008 IO Controller’s Fusion-MPT™ 2.0 architecture can achieve more than 1,000,000 I/Os per second;- Environmentally friendly due to low-power consumption;- MD2 low profile form-factor design;- MD2 form factor ideal for 1U and 2U server.
| Ports & interfaces | |
|---|---|
| Supported storage drive interfaces | SAS,Serial ATA |
| Host interface | PCI Express x8 |
| PCI Express slots version | 3.0 |
| Internal mini-SAS ports | 2 |
| Internal SAS ports | 8 |
| Performance | |
| RAID levels | 0,1 |
| Data transfer rate | 12 Gbit/s |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -45 - 105 °C |
| Other features | |
| PCI Card form factor | Full-height (low-profile) |
